Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Fix the bolts securely using the holes.
1
2
INSTALLATION
DETACHMENT
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
1
Loose the bolts and then detach the stand
from the TV.
2
Detach the
SSTTAANNDD BBOODDYY
from the TV.
4
Loose the bolts from the TV.
And detach the
CCOOVVEERR BBAASSEE
from the TV.
3
SSTTAANNDD BBOODDYY
CCOOVVEERR BBAASSEE
GG
When assembling the desk type stand, make sure
the bolt is fully tightened (If not tightened fully,
the TV can tilt forward after the product installa-
tion). Do not over tighten.
NOTE
26LU50FR
19LU50R, 22LU50FR 26LU50FR
For 19LU50R, 22/26LU50FR
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 26
