PREPARATION
35
Align the hole with the tab on the
CCAABBLLEE
MMAANNAAGGEEMMEENNTT CCLLIIPP
.
Turn the
CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPP
as
shown.
Note: This cable management clip can be bro-
ken by excessive pressure.
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
1
2
HOW TO SECURE THE POWER CABLE
Secure the power cable with the
PPRROOTTEECCTTIIVVEE
BBRRAACCKKEETT
and the bolt as shown. It will help pre-
vent the power cable from being removed by acci-
dent.
PPRROOTTEECCTTIIVVEE BBRRAACCKKEETT
SSCCRR EEWW
For 32/42/47LH70YR
For 19LU50R, 22/26LU50FR, 22LU40R
After connecting the cables as necessary,
install CABLE HOLDER as shown and bundle
the cables.
1
MFL58486305-Edit1-en- 5/28/10 2:32 PM Page 35
