5. Component Video Input (Y, Cb/Pb, Cr/Pr)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remark
1 720*576 15.625 50.00 13.5 SDTV ,DVD 576I
2 720*480 15.73 60.00 13.5135 SDTV ,DVD 480I
3 720*480 15.73 59.94 13.50 SDTV ,DVD 480I
4 720*576 31.25 50.00 27.00 SDTV 576P
5 720*480 31.50 60.00 27.027 SDTV 480P
6 720*480 31.47 59.94 27.00 SDTV 480P
7 1280*720 37.50 50.00 74.25 HDTV 720P
8 1280*720 45.00 60.00 74.25 HDTV 720P
9 1280*720 44.96 59.94 74.176 HDTV 720P
10 1920*1080 28.125 50.00 74.25 HDTV 1080I Except HD Model
11 1920*1080 33.75 60.00 74.25 HDTV 1080I Except HD Model
12 1920*1080 33.72 59.94 74.176 HDTV 1080I Except HD Model
13 1920*1080 56.25 50.00 148.50 HDTV 1080P Except HD Model
14 1920*1080 67.50 60.00 148.50 HDTV 1080P Except HD Model
15 1920*1080 67.432 59.94 148.352 HDTV 1080P Except HD Model
16 1920*1080 27.00 24.00 74.25 HDTV 1080P Except HD Model
17 1920*1080 26.97 23.94 74.176 HDTV 1080P Except HD Model
18 1920*1080 33.75 30.00 74.25 HDTV 1080P Except HD Model
19 1920*1080 33.71 29.97 74.176 HDTV 1080P Except HD Model
