SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application range
This spec sheet is applied all of the LED TV with LT46H
chassis.
2. Test condition
Each part is tested as below without special notice.
1) Temperature : 25 ºC ± 5 ºC(77 ± 9 ºF), CST : 40 ºC±5 ºC
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
Standard input voltage (100~240V@ 50/60Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 20 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety : CE, IEC specification
- EMC: CE, IEC
4. Model Specification
No Item Specication Remark
1. Market Taiwan, Colombia, Panama
2. Broadcasting system Digital : DVB-T
Analog : NTSC-M / PAL-M / PAL-N
Taiwan: NTSC-M / Colombia : DVB-T/T2
3. Available Channel BAND NTSC Colombia : DVB-T2 (DTV : 7 ~69)
VHF
UHF
CATV
DTV
2 ~ 13
14 ~ 69
1 ~ 125
14 ~ 69
4. Receiving system Digital : DVB-T
Analog : NTSC-M / PAL-M / PAL-N
Taiwan: NTSC-M / Colombia : DVB-T/T2
5. Video Input NTSC-M Rear : 1EA(Common AV/Component)
6. Component Input Y/Cb/Cr, Y/ Pb/Pr Rear (1EA)
7. RGB Input RGB-PC, Spec out
8. HDMI Input PC(HDMI version 1.3) / DTV format,
Support HDCP
Side 3EA
Support ARC only HDMI1
Support MHL only HDMI3
9. Audio Input Component / AV Audio / DVI Audio, Rear : 1EA(Common Component / AV / DVI)
10 Headphone Audio out through Headphone Rear (1EA)
11 SPDIF out Optical Audio out Rear (1EA),
12 USB Input EMF, DivX HD, For SVC (download) Side 3EA
JPEG, MP3, DivX HD
