SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement.
1. Application Range. 3. Test method
This spec sheet is applied to the 32"/42" LCD TV used
LF7300, LH3300 chassis. 3.1 Performance : LGE TV test method followed.
3.2 Demanded other specification
2. Specification
Safety : CE, IEC specification
Each part is tested as below without special appointment
EMC : CE, IEC
2.1 Temperature : 25±5°C(77±9°F), CST : 40±5°C
2.2 Relative Humidity : 65±10%
2.3 Power Voltage : Standard input voltage
(100-240V ~50/60Hz)
• Standard Voltage of each products is marked by models
2.4 Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM .
2.5 The receiver must be operated for about 5 minutes prior to
the adjustment.
4. General Specification
No Item Specification Remark
1 Display Screen Device 32”/42” wide Color Display Module
2 Aspect Ratio 16:9
MAKER : 32” – LGD
42”–LGD
3 Operating Environment
Temp. : 5 ~ 35 deg
Humidity : 10 ~ 90%
LGE SPEC.
4 Storage Environment
Temp. : -20 ~ 50 deg
Humidity : 10 ~ 90 %
5 Input Voltage AC100 - 240V ~50/60Hz
6 Power Consumption
Power ON
A unit : W
32LF7300 170
42LF7300 215
32LH3300 165
42LH3300 205
7 Module Size
32LF7300 760.0(H) x 450.0(V) x 48.0(D)
A unit : mm
42LF7300 983.0(H) x 576.0(V) x 46.0(D)
32LH3300 760.0(H) x 450.0(V) x 48.0(D)
42LH3300 983.0(H) x 576.0(V) x 46.0(D)
8
Pixel Pitch
32LF7300 0.36375(H) x 0.36375(V)
A unit : mm
42LF7300 0.4845(H) x 0.4845(V)
32LH3300 0.36375(H) x 0.36375(V)
42LH3300 0.4845(H) x 0.4845(V)
CCFL
Back Light
32LF7300 EEFL
42LF7300 EEFL
32LH3300 EEFL
42LH3300 EEFL
10 Display Colors 10-bit(D), 1.06 Billion Color
11 Coating 3H, AG
