LG 32LH570B Service Manual

75 pages

To Next Page

To Previous Page

- 6 -

LGE Internal Use Only

Only for training and service purposes

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement

1. Application range

This spec sheet is applied to the LED TV used LA66K chassis

2. Test condition

Each part is tested as below without special notice.

(1) Temperature : 25 ºC±5 ºC (77 ºC±9ºC), CST : 40 ºC±5 ºC

(2) Relative Humidity: 65 % ± 10 %

(3) Power Voltage

Standard input voltage (100~240V@ 50/60Hz)

(4) Specification and performance of each parts are followed

each drawing and specification by part number in

accordance with BOM.

(5) The receiver must be operated for about 20 minutes prior

to the adjustment.

3. Test method

(1) Performance: LGE TV test method followed

(2) Demanded other specification

- Safety : UL, CSA, IEC specification

- EMC: FCC, ICES, IEC specification

4. General Specification

No Item Specication Result Remark

1. Receiving System ATSC / NTSC-M / 64 & 256 QAM

2. Available Channel VHF : 02~13

UHF : 14~69

DTV : 02-69

CATV : 01~135

CADTV : 01~135

3. Input Voltage AC 100 ~ 240V 50/60Hz Mark : 110V, 60Hz

4. Market NORTH AMERICA

5. Screen Size 32", 43”, 49", 55”

6. Aspect Ratio 16:9

7. Tuning System FS

8. Module LC550DUE-FJA1 LGD FHD

NC550DUE-VCCP3 CSOT FHD

NC490DUE-SADP3 LGD FHD

NC490DUE-ABEX1 BOE FHD

HC430DUN-SLVX1 LGD FHD

HC430DUN-ABVX1 BOE FHD

HC320DXN-ABVS1 BOE HD

HC320DXN-SLVS5 LGD HD

HC320DXN-VHVS1 SHARP HD

9. Operating Environment Temp : 0 ~ 40 deg

Humidity : ~ 80 %

10. Storage Environment Temp : -20 ~ 60 deg

Humidity : ~ 85 %

Other manuals for LG 32LH570B

Owner's Manual36 pages

Easy Setup Guide73 pages

Safety And Reference40 pages

Questions and Answers:

M
Michele MorrisJul 27, 2025
What to do if my LG 32LH570B turns off suddenly?
- A
  Andrew GomezJul 27, 2025
  If your LG LED TV turns off suddenly, it might be due to a few reasons. First, the power supply could be interrupted, so check the power control settings. Also, the Sleep Timer or Timer Power Off feature might be activated in the Timers settings. Finally, if there's no signal while the TV is on, it will turn off automatically after 15 minutes of inactivity.

LG 32LH570B Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	32 \
Display brightness	- cd/m²
Display resolution	1366 x 768 pixels
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	Direct-LED
Motion interpolation technology	-
3D	No
Tuner type	Analog & digital
Analog signal format system	NTSC
Processor cores	2
Audio formats supported	AAC, DTS, EAC3, HE-AAC, MP2, MP3, PCM, RA-Lossless, WMA
Video compression formats	HEVC
Picture processing technology	LG Triple XD Engine
Audio decoders	DTS, Dolby Digital
RMS rated power	6 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	SimpLink
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Number of OSD languages	4
Product color	Black
Panel mounting interface	200 x 200 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Sustainability certificates	ENERGY STAR
Package depth	134 mm
Package width	795 mm
Package height	505 mm
Package weight	6200 g
Cables included	AC
Remote control type	L-Con

Weight and Dimensions

Depth (with stand)	172 mm
Width (with stand)	734 mm
Height (with stand)	474 mm
Weight (with stand)	4700 g
Depth (without stand)	66.5 mm
Height (without stand)	438 mm
Weight (without stand)	4500 g
