To Next PageTo Next PageWhat to do if my LG LCD TV fails to power up?
If your LG LCD TV fails to power up, start by inspecting the P401 power connector. If the connector is okay, consider replacing the Power Board. Also, check the Q409 application circuit and the Q409 output Voltage (12V), replacing Q409 if necessary. Inspect the LVDS Cable and replace it, if needed. Finally, check the LCD Module Control board.
What to do if composite video is not working on my LG LCD TV?
If you're experiencing issues with composite video on your LG LCD TV, begin by inspecting the AC cable for any damage or open conductors. Then, check JK1700 and replace it if necessary. Check the input of Mstar(IC101). Measure waveform at C217 because it’s more easy to check. If problems persist, and after rechecking all paths, consider replacing the Mstar chip.
What to do if analog RF video is not working on my LG 32LT670H-UA LCD TV?
If you are experiencing issues with analog RF video on your LG LCD TV, check TU3001 Pin7 and consider replacing the tuner. Also, check the tuner's 5V power at L3000 and inspect IC5000, replacing IC5000 if needed. Check the tuner's 3.3V power at L3001 and replace L3001 if necessary. Check the tuner's 1.8V power at IC3000, ensuring 2pin : 1.8V, and replace IC3000 if needed. Finally, check the Mstar LVDS output and replace IC101 if necessary.
What to do if digital RF is not working on my LG 32LT670H-UA?
If you're having trouble with the digital RF on your LG LCD TV, check the tuner's 5V power at L3000 and inspect IC5000, replacing IC5000 if necessary. Also, check the IIC Signal and replace TU3001 at pins #3 and #4. Check the DIF Signal and replace TU3001 at pins #10 and #11. Finally, check X201 and replace X201 and its application circuit.
General| Screen Size | 32 inches |
|---|---|
| Resolution | 1366 x 768 |
| Display Type | LCD |
| HDMI Ports | 3 |
| USB Ports | 1 |
| Smart TV | Yes |
| Refresh Rate | 60Hz |
| Aspect Ratio | 16:9 |
| Sound Output | 20W |
| Inputs | HDMI, USB, Composite |
| Audio Output | 10W x 2 |
Procedures for cold and hot AC leakage current testing.
Explains the ADC adjustment procedure.
Covers white balance and other final adjustments.
Guides for power-up boot failures and OSD problems.
Guides for analog RF video problems.
Guide for digital RF video problems.
