LG 32LX2D Service Manual

- 30 -
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C514 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C517 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C518 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C519 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C521 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C525 0CK102CK56A 1000PF 1608 50V 0.1 R/TP X7
C528 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C529 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C532 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C534 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C535 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C536 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C539 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C540 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C542 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C546 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C547 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C548 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C549 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C550 0CK222CK51A 2200PF 1608 50V 10% R/TP B(
C553 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C556 0CK105DK94A "1UF 2012 50V 80%,-20% R/TP"
C557 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C560 0CK105DK94A "1UF 2012 50V 80%,-20% R/TP"
C561 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C564 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C569 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C579 0CK333CK56A 33000PF 1608 50V 10% R/TP X
C580 0CK333CK56A 33000PF 1608 50V 10% R/TP X
C581 0CK333CK56A 33000PF 1608 50V 10% R/TP X
C582 0CK333CK56A 33000PF 1608 50V 10% R/TP X
C594 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C595 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C596 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C626 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C632 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C651 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C654 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C658 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C661 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C674 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C675 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C701 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C101 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C104 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C115 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C116 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C223 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C323 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C326 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C413 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C502 0CH2152K516 1500PF 50V 10% B(Y5P) 2012
C505 0CH2152K516 1500PF 50V 10% B(Y5P) 2012
C538 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C543 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C554 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C583 0CE108EJK18 "1000UF KMG,RD 35V 20%,-20%"
C597 0CE108EJK18 "1000UF KMG,RD 35V 20%,-20%"
C111 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C226 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C227 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C307 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C308 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C309 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C414 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C415 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C416 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C417 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C418 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C426 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C429 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C431 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C432 0CE105SK6DC 1UF MVG 50V 20% SMD R/TP
C433 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C436 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C438 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C443 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C507 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C511 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C520 0CE335SK6DC 3.3UF MVG 50V 20% SMD R/TP
C531 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C533 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C544 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C555 0CE335SK6DC 3.3UF MVG 50V 20% SMD R/TP
C563 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C566 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C567 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C576 0CE475VK6DC 4.7UF MV 50V 20% R/TP(SMD)
C577 0CE475VK6DC 4.7UF MV 50V 20% R/TP(SMD)
C602 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C604 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C607 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C612 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C613 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C616 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C617 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C620 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C621 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C629 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C633 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C635 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C636 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C639 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C640 0CE476VK6DC 47UF MV 50V 20% R/TP(SMD) S
C641 0CE476VK6DC 47UF MV 50V 20% R/TP(SMD) S
C644 0CE107VH6DC 100UF MV 25V 20% R/TP(SMD)
C646 0CE107VH6DC 100UF MV 25V 20% R/TP(SMD)
C652 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C655 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C657 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C659 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C660 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C663 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C665 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C666 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C672 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C681 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C584 0CF4741L438 0.47UF D 63V 5% TP 5 M/PE N
C585 0CF4741L438 0.47UF D 63V 5% TP 5 M/PE N
ZD101 0DR050008AA SD05.TC R/TP SEMTECH SOD323
ZD102 0DR050008AA SD05.TC R/TP SEMTECH SOD323
