LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
ZD301 0DR050008AA SD05.TC R/TP SEMTECH SOD323
ZD302 0DR050008AA SD05.TC R/TP SEMTECH SOD323
D101 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D102 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D103 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D403 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D404 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D601 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D602 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D603 0DS226009AA KDS226 TP KEC - 80V - - 4NS
ZD108 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD109 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD303 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD304 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD501 0DZ820009AH MTZJ8.2B TP ROHM-K DO34 - 8
IC403 0IMMRMR006E "MX29LV160BTTC-70G,LF MACRON"
IC101 0IMMR00018A 24LC02BT-I/SNG(PB FREE) MIC
IC402 0IMMRHY001L "HY57V641620ETP-H,LF HYNIX 5"
IC404 0IMCRAL006A "AT24C16AN-10SU-2.7,LF ATMEL"
IC301 0ISO206900A CXA2069Q QFP64 BK I2C BUS A
IC401 0IMCRMN023A SDA6001 QH B12 MICRONAS 128
IC501 0IMCRMN028B MSP4410K MICRONAS 80P/PQFP
IC502 0IMCRNL001C "NSP-6241B,PB FREE NEOFIDELI"
IC503 0IMCRTI028C "TAS5122DCARG4,LF TEXAS INS"
IC405 0IKE702700D "KIA7027AF 3, SOT-89 TP RESE"
IC601 0IMCRFA010A "KA7809R, FAIRCHILD 2P D-PAK"
IC602 0IPRPML001A MIC39100 MICREL 3P SOT223 R
IC603 0IPMGKE030A KIA78R05F KEC 5PIN DPAK R/T
L506 6140VB0022A CPS-0810 GET 22UH 21.5TURNS
L507 6140VB0022A CPS-0810 GET 22UH 21.5TURNS
L508 6140VB0022A CPS-0810 GET 22UH 21.5TURNS
L509 6140VB0022A CPS-0810 GET 22UH 21.5TURNS
R707 6210TCE001P HB-1S2012-121JT CERATECH 20
R708 6210TCE001P HB-1S2012-121JT CERATECH 20
L600 6210TCE001P HB-1S2012-121JT CERATECH 20
L601 6210TCE001P HB-1S2012-121JT CERATECH 20
L602 6210TCE001P HB-1S2012-121JT CERATECH 20
L603 6210TCE001P HB-1S2012-121JT CERATECH 20
L206 6210VC0005A BK2125 HS 750 TAIYOYUDEN 2X
L208 6210VC0005A BK2125 HS 750 TAIYOYUDEN 2X
L209 6210VC0005A BK2125 HS 750 TAIYOYUDEN 2X
L211 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L216 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L217 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L218 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L303 6210TCE001A HB-1S2012-080JT CERATEC 201
L305 6210TCE001A HB-1S2012-080JT CERATEC 201
L307 6210TCE001A HB-1S2012-080JT CERATEC 201
L309 6210TCE001A HB-1S2012-080JT CERATEC 201
L311 6210TCE001A HB-1S2012-080JT CERATEC 201
L408 6210TCE001G HH-1M3216-501 CERATEC 3216M
L510 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L511 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L613 6210TCE001G HH-1M3216-501 CERATEC 3216M
L614 6210TCE001G HH-1M3216-501 CERATEC 3216M
L616 6210TCE001G HH-1M3216-501 CERATEC 3216M
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L618 6210TCE001G HH-1M3216-501 CERATEC 3216M
L619 6210TCE001G HH-1M3216-501 CERATEC 3216M
L620 6210TCE001G HH-1M3216-501 CERATEC 3216M
L621 6210TCE001G HH-1M3216-501 CERATEC 3216M
L622 6210TCE001G HH-1M3216-501 CERATEC 3216M
L108 6210TCE001G HH-1M3216-501 CERATEC 3216M
L302 6210TCE001G HH-1M3216-501 CERATEC 3216M
L405 6210TCE001G HH-1M3216-501 CERATEC 3216M
L407 6210TCE001G HH-1M3216-501 CERATEC 3216M
L608 6210TCE001G HH-1M3216-501 CERATEC 3216M
L609 6210TCE001G HH-1M3216-501 CERATEC 3216M
L624 6210TCE001G HH-1M3216-501 CERATEC 3216M
L625 6210TCE001G HH-1M3216-501 CERATEC 3216M
L626 6210TCE001G HH-1M3216-501 CERATEC 3216M
L627 6210TCE001G HH-1M3216-501 CERATEC 3216M
L629 6210TCE001G HH-1M3216-501 CERATEC 3216M
L630 6210TCE001G HH-1M3216-501 CERATEC 3216M
L700 6210TCE001G HH-1M3216-501 CERATEC 3216M
L109 0LC2000005H "FI-B2012-472,4.7UH CERATECH"
L110 0LC2000005H "FI-B2012-472,4.7UH CERATECH"
L202 0LC0233002A 3.3UH CERATECH R/TP
L204 0LC0233002A 3.3UH CERATECH R/TP
L212 0LC0233002A 3.3UH CERATECH R/TP
L213 0LC0233002A 3.3UH CERATECH R/TP
L214 0LC0233002A 3.3UH CERATECH R/TP
L215 0LC0233002A 3.3UH CERATECH R/TP
L501 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
L502 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
L504 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
L512 0LC1020101A 1UH 10% 2012 R/TC FI-B2012-
L513 0LC1020101A 1UH 10% 2012 R/TC FI-B2012-
L503 0LC2232101A 22UH 10% 3216 R/TC FI-D3216
L640 0LC6832101A 6.8UH 10% 3216 R/TC FI-C321
Q101 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q102 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q103 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q204 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q205 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q206 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q307 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q501 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q502 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q503 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q504 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q505 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q506 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q507 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q508 0TR102008AA KRA102S R/TP KEC SOT23 CHIP
Q301 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q302 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q303 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q304 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q305 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q306 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q308 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
L304 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
- 31 -
TRANSISTOR
RESISTORs
IC
COIL & CORE & & FILTER & INDUCTOR
