LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L306 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L308 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L310 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L312 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L313 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L314 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R101 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R102 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R103 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R104 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R105 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R107 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R108 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R109 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R110 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R111 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R112 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R113 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R114 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R117 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R128 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R129 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R132 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R133 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R135 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R136 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R137 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R138 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R139 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R140 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R141 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R201 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R203 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R205 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R208 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R210 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R212 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R214 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R220 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R222 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R237 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R238 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R239 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R240 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R241 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R244 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R245 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R246 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R247 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R248 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R251 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R252 0RH2203D622 220K OHM 1 / 10 W 2012 5.00
R253 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R254 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R315 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R316 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R332 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R336 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R338 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R340 0RH1201D622 1.2K OHM 1 / 10 W 2012 5.00
R341 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R342 0RH1201D622 1.2K OHM 1 / 10 W 2012 5.00
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R343 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R348 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R349 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R350 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R351 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R356 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R358 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R405 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R407 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R412 0RH8200D622 820 OHM 1 / 10 W 2012 5.00%
R413 0RH1801D622 1.8K OHM 1 / 10 W 2012 5.00
R418 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R437 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R438 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R439 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R442 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R443 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R5 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R501 0RH3300D622 330 OHM 1 / 10 W 2012 5.00%
R502 0RH1202D622 12K OHM 1 / 10 W 2012 5.00%
R503 0RH3901D622 3.9K OHM 1 / 10 W 2012 5.00
R508 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R510 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R511 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R513 0RH0432D622 43 OHM 1 / 10 W 2012 5.00%
R514 0RH0432D622 43 OHM 1 / 10 W 2012 5.00%
R516 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R525 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R526 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R541 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R559 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R560 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R561 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R562 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R563 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R564 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R565 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R566 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R567 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R568 0RH0221D622 2.2 OHM 1 / 10 W 2012 5.00%
R569 0RH0221D622 2.2 OHM 1 / 10 W 2012 5.00%
R570 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R572 0RH0221D622 2.2 OHM 1 / 10 W 2012 5.00%
R573 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R574 0RH0221D622 2.2 OHM 1 / 10 W 2012 5.00%
R575 0RH0331D622 3.3 OHM 1 / 10 W 2012 5.00%
R579 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R581 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R582 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R583 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R584 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R585 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R586 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R587 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R590 0RH0331D622 3.3 OHM 1 / 10 W 2012 5.00%
R591 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R595 0RH0101D622 1.0 1/10W 5 TA
R599 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R6 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R7 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R701 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R703 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
