LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R704 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R705 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R706 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R711 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R713 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R724 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R725 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R8 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R115 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R116 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R130 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R131 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R134 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R2 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R301 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R302 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R304 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R305 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R306 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R307 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R309 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R310 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R311 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R312 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
R313 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R314 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R319 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R320 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R321 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R322 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R323 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R324 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R325 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R326 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R327 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/T
R328 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/T
R329 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R333 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R334 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R335 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/T
R337 0RJ1201D677 1200 OHM 1/10 W 5% 1608 R/T
R339 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R346 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R347 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R352 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R353 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R354 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R4 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R401 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R402 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R419 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R420 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R421 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R422 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R429 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R430 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R431 0RJ3301D677 3.3K OHM 1/10 W 5% 1608 R/T
R432 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R433 0RJ8201D677 8.2K OHM 1/10 W 5% 1608 R/T
R436 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R504 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R505 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R506 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R507 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R517 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R518 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R519 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R521 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R524 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R527 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R530 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R532 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R533 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R536 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R537 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R538 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R539 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R540 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R542 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R543 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R544 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R545 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R546 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R547 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R548 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R549 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R550 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R552 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R553 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R554 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R555 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R556 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R557 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R558 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R571 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R576 0RJ0221D677 2.2 OHM 1/10 W 5% 1608 R/TP
R577 0RJ0221D677 2.2 OHM 1/10 W 5% 1608 R/TP
R578 0RJ0221D677 2.2 OHM 1/10 W 5% 1608 R/TP
R580 0RJ0221D677 2.2 OHM 1/10 W 5% 1608 R/TP
R588 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/T
R589 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/T
R592 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R593 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R594 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R596 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R597 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R598 0RJ0101D677 1 OHM 1/10 W 5% 1608 R/TP
R601 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R718 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R719 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R720 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R721 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R722 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R723 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
X401 6202TST001C "SX-1, SUNNY SMD, 6.0MHZ ,50"
X501 6202VDT002H SX-1 SUNNY 18.432000MHZ +/-
TU2 6634D00014B TASA-G204D LG INNOTEK 75 OH
- 33 -
