LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C329 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C330 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C331 0CK474CH94A "0.47UF 1608 25V 80%,-20% R/"
C353 0CK473CK56A 47000PF 1608 50V 10% R/TP X
C354 0CK473CK56A 47000PF 1608 50V 10% R/TP X
C355 0CK473CK56A 47000PF 1608 50V 10% R/TP X
C361 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C370 0CK823CK56A 82NF 1608 50V 10% R/TP X7R
C373 0CK822CK56A 8200PF 1608 50V 10% X7R R/T
C376 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C381 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C447 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C448 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C455 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C461 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C462 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C468 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C469 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C515 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C536 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C540 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C548 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C552 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C619 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C719 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C722 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C723 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C724 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C804 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C805 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C806 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C809 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C810 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C814 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C815 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C816 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C817 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C818 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C901 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C904 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C905 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C911 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C961 0CK472CK51A 4700PF 1608 50V 10% R/TP B(
C963 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C976 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C214 0CH2224F946 "0.22UF 16V 80%,-20% F(Y5V)"
C218 0CH2152K516 1500PF 50V 10% B(Y5P) 2012
C226 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C230 0CH2152K516 1500PF 50V 10% B(Y5P) 2012
C232 0CH2473K516 47000PF 50V 10% B(Y5P) 2012
C233 0CH2473K516 47000PF 50V 10% B(Y5P) 2012
C237 0CH2152K516 1500PF 50V 10% B(Y5P) 2012
C239 0CH2473K516 47000PF 50V 10% B(Y5P) 2012
C304 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C311 0CH6101K416 100PF 50V 5% NP0 2012 R/TP
C319 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C320 0CH2474F566 0.47UF 16V 10% X7R 2012 R/T
C1500 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C1502 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C1503 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C1504 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C1506 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1507 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C1509 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C227 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C228 0CC391CK41A 390PF 1608 50V 5% NP0 R/TP
C262 0CC030CK01A 3PF 1608 50V 0.25 PF R/TP N
C263 0CC181CK41A 180PF 1608 50V 5% R/TP NP0
C352 0CC471CK41A 470PF 1608 50V 5% R/TP NP0
C385 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C422 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C424 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C711 0CC821CK41A 820PF 1608 50V 5% R/TP NP0
C727 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C801 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C819 0CC300CK41A 30PF 1608 50V 5% R/TP NP0
C831 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C972 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
C975 0CC470CK41A 47PF 1608 50V 5% R/TP NP0
R217 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
R261 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C1003 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1004 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C104 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1404 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1407 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1409 0CE476VK6DC 47UF MV 50V 20% R/TP(SMD) S
C1512 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1515 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1518 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1521 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1524 0CE476WK6DC 47UF MVK 50V 20% R/TP(SMD)
C1526 0CE476WK6DC 47UF MVK 50V 20% R/TP(SMD)
C1585 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1586 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1587 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1588 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1589 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1590 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C1591 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1592 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1593 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1594 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1595 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1596 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1597 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1598 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1599 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1600 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1601 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1602 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1603 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1604 0CE226WF6DC 22UF MVK 16V 20% R/TP(SMD)
C1605 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1606 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1607 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1608 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1609 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C1610 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1611 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1612 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1613 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1614 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1615 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
- 37 -
