LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1616 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1617 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1619 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1621 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1624 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1625 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1628 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C1629 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1631 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1632 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C1633 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1637 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C1642 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1644 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1645 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1648 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD)
C1651 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C1657 0CE477WF6DC 470UF MVK 16V 20% SMD R/TP(
C1658 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C1659 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1660 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C1663 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C1664 0CE476WF6DC 47UF MVK 16V 20% R/TP(SMD)
C203 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C204 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C205 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C206 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C207 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C208 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C209 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C252 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C356 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C368 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C377 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C384 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C388 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C401 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C402 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C426 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C446 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C550 0CE106WFKDC "10UF MVK 16V 20%,-20% SMD R"
C551 0CE106WFKDC "10UF MVK 16V 20%,-20% SMD R"
C602 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C605 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C608 0CE105SK6DC 1UF MVG 50V 20% SMD R/TP
C614 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C616 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C618 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C728 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C729 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C812 0CE106WFKDC "10UF MVK 16V 20%,-20% SMD R"
C813 0CE106WFKDC "10UF MVK 16V 20%,-20% SMD R"
C827 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C902 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C903 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C909 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C918 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C953 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C954 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C955 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C973 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
C974 0CE226SF6DC 22UF MVG 16V 20% SMD R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
D104 0DD184009AA KDS184 TP KEC - 85V - - - 3
D1101 0DD184009AA KDS184 TP KEC - 85V - - - 3
D801 0DS181009AA KDS181 TP KEC SOT-23 80V
IC1003 0ICTMLG013A LGDT1901A LG IC 24P SSOP TR
IC1301 0ICTMLG018B LGDP4411 IEP2 LG IC 208P LQ
IC701 0ICTMLG009C LGDT1102C HD2.3 LG IC SBGA-
IC301 0ILNRMN005B VPX3226F MICRONAS 44PIN PMQ
IC902 0IMMRAL016D AT49BV160C-70TU ATMEL 48P T
IC903 0IMMRAL016D AT49BV160C-70TU ATMEL 48P T
IC102 0IMMR00018A 24LC02BT-I/SNG(PB FREE) MIC
IC702 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC703 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC704 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC705 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC803 0IMMR00022A 24LC16BT-I/SNG(PB FREE) MIC
IC904 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC905 0IMMRSS041G "K4S641632H-UC75,LF SAMSUNG"
IC906 0IMMR00024A 24LC256T-I/SMG(PB FREE) MIC
IC1001 0IMCRXL004A "XC95288XL-10TQG144C,LF XIL"
IC1004 0IMCRCY002A CY2309SXC-1HT CYPRESS SOIC
IC1101 0IMCRPH026A PCA9516PW PHILIPS 16P TSSOP
IC1102 0IMCRSG010A ST3232CDR SGS-THOMSON SOP16
IC401 0IMCRSO025A CXA2181Q SONY 48P QFP TRAY
IC901 0IMCRSS016A S3C44BOX01-EDRO SAMSUNG ELE
IC1501 0IMI623200B "M62320FP,I/O EXPANDER 16P S"
IC801 0IPRPMI006A M37272E8SP(OTP) MITSUBISHI
IC1005 0IPRP00548A "CY25560SXCT,LF CYPRESS 8P,S"
IC1202 0ICB841500B CS8415A-CZR 28P TSSOP R/TP
IC1205 0ICB533100A CS5331A-KSR 8SOIC TP ADC -
IC1401 0ITH638300C "THC63LVDM83R(F),LF THINE EL"
IC201 0IIT323000E VPC3230D C5 80P QFP TRAY VI
IC501 0IPRPAD008B "AD9883AKST(Z)-110,LF ANALOG"
IC601 0IPRPS5005A SII9011CLU(PB FREE) SILICON
IC1103 0IKE702900G KIA7029AF SOT-89 TP 2.9V VO
IC1601 0IPMGKE030A KIA78R05F KEC 5PIN DPAK R/T
IC1603 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC1604 0IMCRFA010A "KA7809R, FAIRCHILD 2P D-PAK"
IC1605 0IPRPML001A MIC39100 MICREL 3P SOT223 R
IC1607 0IPMGKE030A KIA78R05F KEC 5PIN DPAK R/T
IC1609 0IPMGKE030A KIA78R05F KEC 5PIN DPAK R/T
IC1610 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC1611 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
IC802 0IKE704200J KIA7042AF SOT-89 TP 4.2V VO
IC1602 0IRH033200A BA033FP-E2 MOLD-3 TP REGULA
IC1606 0IRH033200A BA033FP-E2 MOLD-3 TP REGULA
IC1608 0IRH033200A BA033FP-E2 MOLD-3 TP REGULA
IC103 0IMCRTI003A SN74HCT08D TEXAS INSTRUMENT
IC1104 0IPH741400E 74HC14D 14SOP TP SHITTER TR
IC1201 0IMCRFA013A 74LCX244MTC FAIRCHILD 20P T
IC1203 0ITO741570C "TC74LCX157FT 16P,TSSOP TP Q"
IC1206 0ISTL00029A "MC33078DR2G,LF ON SEMI 8P,S"
L1639 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1640 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1641 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
L1642 6140VB0004B 26UH 1UEWPHY 22.5TURN YL-9N
- 38 -
DIODEs
IC
COIL & CORE & & FILTER & INDUCTOR
