LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L1501 6210TCE001P HB-1S2012-121JT CERATECH 20
L1508 6210TCE001P HB-1S2012-121JT CERATECH 20
R1602 6210TCE001P HB-1S2012-121JT CERATECH 20
R1607 6210TCE001P HB-1S2012-121JT CERATECH 20
L1513 6210TCE001P HB-1S2012-121JT CERATECH 20
R1506 6210TCE001P HB-1S2012-121JT CERATECH 20
R1507 6210TCE001P HB-1S2012-121JT CERATECH 20
R1508 6210TCE001P HB-1S2012-121JT CERATECH 20
R1509 6210TCE001P HB-1S2012-121JT CERATECH 20
R1510 6210TCE001P HB-1S2012-121JT CERATECH 20
R1511 6210TCE001P HB-1S2012-121JT CERATECH 20
IC502 0IZZVF0022D AFM118F6M00X1(AF-9424C) MUR
L101 6210TCE001G HH-1M3216-501 CERATEC 3216M
L105 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1101 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1201 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1402 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1602 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1605 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1606 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1607 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1608 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1609 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1610 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1611 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1612 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1613 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1614 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1615 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1616 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1619 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1620 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1621 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1624 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1625 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1627 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1628 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1629 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1630 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1631 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1633 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1634 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1635 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1636 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1637 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1638 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1643 6210TCE001G HH-1M3216-501 CERATEC 3216M
L402 6210TCE001A HB-1S2012-080JT CERATEC 201
L404 6210TCE001A HB-1S2012-080JT CERATEC 201
L406 6210TCE001A HB-1S2012-080JT CERATEC 201
L408 6210TCE001A HB-1S2012-080JT CERATEC 201
L601 6210TCE001G HH-1M3216-501 CERATEC 3216M
L602 6210TCE001G HH-1M3216-501 CERATEC 3216M
L801 6210TCE001G HH-1M3216-501 CERATEC 3216M
L802 6210TCE001G HH-1M3216-501 CERATEC 3216M
L803 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1401 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1509 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1510 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1511 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1618 6210TCE001G HH-1M3216-501 CERATEC 3216M
L1622 6210TCE001G HH-1M3216-501 CERATEC 3216M
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L1626 6210TCE001G HH-1M3216-501 CERATEC 3216M
Q1401 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q1402 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q401 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q501 0TR102009AG CHIP KRC102S KEC TP SOT-23
Q901 0TR102008AA KRA102S R/TP KEC SOT23 CHIP
Q201 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q202 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q203 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q402 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q403 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q404 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q405 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q406 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q601 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q602 0TR830009BA BSS83 TP PHILIPS NON N-CHAN
Q801 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q802 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q803 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q805 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q902 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q903 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
IC1402 0TF492509AA SI4925DY TP TEMIC 30V 6.1A
AR1001 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1002 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1003 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1004 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1005 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1006 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1007 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1008 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1009 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1010 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1011 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1012 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1401 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR1402 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR901 0RRZVTA001C 4.7K OHM 1 / 16 W 1608 5% R
AR902 0RRZVTA001C 4.7K OHM 1 / 16 W 1608 5% R
R310 0RN1002F409 10K OHM 1/6 W 1.00% TA52
L401 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L403 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L405 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L407 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L409 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L410 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R100 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R101 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1012 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R1018 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R102 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1020 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1028 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R1029 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R1042 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1044 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
- 39 -
TRANSISTOR
RESISTORs
