LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1045 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1046 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1047 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1055 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1056 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1057 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1058 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1402 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1404 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1405 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1406 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R1501 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R1502 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R151 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1512 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1513 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R1514 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R152 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R153 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R154 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R156 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1601 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1605 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1606 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R1608 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R171 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R182 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R184 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R198 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R199 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R219 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R220 0RH2002D622 20K OHM 1 / 10 W 2012 5.00%
R221 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R222 0RH2002D622 20K OHM 1 / 10 W 2012 5.00%
R223 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R224 0RH2002D622 20K OHM 1 / 10 W 2012 5.00%
R237 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R238 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R239 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R240 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R244 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R247 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R250 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R263 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R264 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R265 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R277 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R304 0RH4700D622 470 OHM 1 / 10 W 2012 5.00%
R305 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R306 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R321 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R329 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R330 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R352 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R353 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R354 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R370 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R371 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R372 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R373 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R374 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R406 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R409 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R410 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R423 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R460 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R463 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R466 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R479 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R483 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R486 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R495 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R496 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R498 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R499 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R500 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R502 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R503 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R504 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R505 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R506 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R507 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R601 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R604 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R606 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R609 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R613 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R615 0RH2401D622 2.4K OHM 1 / 10 W 2012 5.00
R617 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R625 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R630 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R636 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R638 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R639 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R645 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R647 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R649 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R651 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R658 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R664 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R666 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R675 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R676 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R707 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R719 0RH3901D622 3.9K OHM 1 / 10 W 2012 5.00
R720 0RH3901D622 3.9K OHM 1 / 10 W 2012 5.00
R724 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R725 0RH3301D622 3.3K OHM 1 / 10 W 2012 5.00
R726 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R727 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R728 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R729 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R730 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R731 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R741 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R760 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R763 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R769 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R819 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R820 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R821 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R822 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R823 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R824 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
- 40 -
