LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R825 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R826 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R850 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R851 0RH0222D622 22 OHM 1 / 10 W 2012 5.00%
R883 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R885 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R887 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R892 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R893 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R903 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R906 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R907 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R914 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R920 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R951 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R952 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R953 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R957 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R958 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R961 0RH1201D622 1.2K OHM 1 / 10 W 2012 5.00
R962 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R965 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R967 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R970 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R986 0RH4702D622 47K OHM 1 / 10 W 2012 5.00%
R990 0RH6801D622 6.8K OHM 1 / 10 W 2012 5.00
AR601 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
AR602 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
AR603 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
AR604 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
AR605 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
AR606 0RJ0000C605 0 OHM 1/16 W 5% 1608 ARRAY
C219 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R1 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1010 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1011 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1015 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1016 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1021 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1022 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1023 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1024 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1025 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1026 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1027 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R103 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R104 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1048 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R105 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R107 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R108 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R109 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R110 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R111 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R112 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R117 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R119 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R120 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R125 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R126 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R1403 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R1407 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R1408 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1409 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1410 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R1412 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1413 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1503 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1504 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R1505 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R173 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R174 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R175 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R176 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R177 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R178 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R1806 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R1807 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R183 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R186 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R187 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R190 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R191 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R192 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R193 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R194 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R197 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R205 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R206 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R207 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R216 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R225 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
R226 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
R227 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
R228 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R229 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R230 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R231 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R232 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R233 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R234 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R235 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R236 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R241 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R242 0RJ0331D677 3.3 OHM 1/10 W 5% 1608 R/TP
R243 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R245 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R246 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R248 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R249 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R260 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R268 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R269 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R270 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R271 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R272 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R273 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R274 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R275 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R276 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R278 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R279 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R280 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R301 0RJ0822D677 82 OHM 1/10 W 5% 1608 R/TP
- 41 -
