LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R655 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R657 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R659 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R661 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R665 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R667 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R668 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R672 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R677 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R702 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R703 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R704 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R705 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R706 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R708 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R709 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R710 0RJ0332D677 33 OHM 1/10 W 5% 1608 R/TP
R711 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R712 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R713 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R714 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R715 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R716 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R717 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R718 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R721 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R722 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R732 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R733 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R734 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R736 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R738 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R739 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R740 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R744 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R745 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R748 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R753 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R754 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R757 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R758 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R759 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R761 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R762 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R767 0RJ3901D677 3.9K OHM 1/10 W 5% 1608 R/T
R770 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R773 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R801 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R802 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R803 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R804 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R805 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R806 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R807 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R808 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R809 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R810 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R815 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R817 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R818 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R827 0RJ1602D677 16K OHM 1/10 W 5% 1608 R/TP
R828 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R829 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R830 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R831 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R832 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R833 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R834 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R835 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R836 0RJ4702D677 47000 OHM 1/10 W 5% 1608 R/
R837 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R838 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R839 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R841 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R842 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R844 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R845 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R846 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R847 0RJ6202D677 62K OHM 1/10 W 5% 1608 R/TP
R848 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R849 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R852 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R853 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R854 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R855 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R856 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R857 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R858 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R859 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R860 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R861 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R862 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R863 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R864 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R866 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R867 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R868 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R870 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R872 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R873 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R874 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R877 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R879 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R881 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R884 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R888 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R889 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R890 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R891 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R894 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R895 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R896 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R897 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R898 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R899 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R901 0RJ6201D677 6.2K OHM 1/10 W 5% 1608 R/T
R902 0RJ6201D677 6.2K OHM 1/10 W 5% 1608 R/T
R904 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/T
R905 0RJ2201D677 2200 OHM 1/10 W 5% 1608 R/T
R921 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R922 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R923 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R924 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R926 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
- 43 -
