LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R930 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
R931 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R933 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R934 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R939 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R954 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R955 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R956 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R959 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R960 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R964 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R966 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R968 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R969 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R975 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R976 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R977 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R978 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R979 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R981 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R983 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R984 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R987 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R988 0RJ6801D677 6800 OHM 1/10 W 5% 1608 R/T
R989 0RJ2700D677 270 OHM 1/10 W 5% 1608 R/TP
R991 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
DL1601 0DL233309AC SAM2333 TP KWANG GREEN/RED
DL1602 0DL233309AC SAM2333 TP KWANG GREEN/RED
X1001 6204B60001B VCXO BUBANG 27MHZ +/- 100 P
X201 6202VDB007B HC49U SUNNY RADIAL 20.250MH
X301 6202VDB007B HC49U SUNNY RADIAL 20.250MH
X402 6212AB3004D CSALF2M69G4ZF01-A3 MURATA 2
X401 6212AB2015A HC-49/SM4H BUBANG 4MHZ +/-
X601 6212AB2845A ABLS-27.000MHZ-16-B-4Y-F-T
X801 6202VDT002D SX-1SMD SUNNY RADIAL 8.0MHZ
X901 6212AB2015E HC-49/SM BUBANG 10.0MHZ +/-
IC801 381-204B 42PIN(1.78-15.24AMMON)
SW1101 6600VR1004A SKHMPW 5P CHIP TACT J-ALPS
SW1101 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1102 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1103 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1104 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1105 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1106 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1107 140-313B TACT 2LEAD 160G(TA) LG C&D
SW1108 140-313B TACT 2LEAD 160G(TA) LG C&D
R1101 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1102 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1103 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1104 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1105 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R1106 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
ZD1201 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD1202 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD1203 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD1204 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
ZD1205 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
ZD1206 0DZ510009EE UDZ S 5.1B TP ROHM-K SOD323
C102 0CH5270K416 27PF 50V 5% NP0 2012 R/TP
C103 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C107 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C109 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C110 0CH5270K416 27PF 50V 5% NP0 2012 R/TP
C113 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C116 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C118 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C120 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C122 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C123 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C125 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C129 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C130 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
C132 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C134 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C136 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C137 0CH2103K666 0.01UF 50V 20% X7R 2012 R/T
D101 0DS226009AA KDS226 TP KEC - 80V - - 4NS
D102 0DS226009AA KDS226 TP KEC - 80V - - 4NS
L101 6210TCE001G HH-1M3216-501 CERATEC 3216M
L102 6210TCE001G HH-1M3216-501 CERATEC 3216M
L106 6210TCE001G HH-1M3216-501 CERATEC 3216M
L107 6210TCE001G HH-1M3216-501 CERATEC 3216M
Q104 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q105 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q107 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
R111 0RH0102D622 10 OHM 1 / 10 W 2012 5.00%
R112 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R113 0RH2201D622 2.2K OHM 1 / 10 W 2012 5.00
R114 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R117 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
R118 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R124 0RH2700D622 270 OHM 1 / 10 W 2012 5.00%
R125 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R140 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R143 0RH3300D622 330 OHM 1 / 10 W 2012 5.00%
R144 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R145 0RH4701D622 4.7K OHM 1 / 10 W 2012 5.00
R147 0RH1002D622 10K OHM 1 / 10 W 2012 5.00%
R151 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R152 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
TU101 6700MF0012A TAUM-W101P LGIT MULTI FS PH
TU102 6700DF0001A TDFB-Z205P LG INOTEK DIGITA
AR101 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR102 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
AR103 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/T
C104 0CE475VK6DC 4.7UF MV 50V 20% R/TP(SMD)
C105 0CE475VK6DC 4.7UF MV 50V 20% R/TP(SMD)
C106 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C117 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C119 0CE227SF6DC 220UF MVG 16V 20% R/TP(SMD)
C121 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C124 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(
C126 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C131 0CE107SF6DC 100UF MVG 16V 20% SMD R/TP
C133 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
- 44 -
OTHERs
CONTROL BOARD
TUNER BOARD
