LG 32LX2D Service Manual

DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C135 0CE476SF6DC 47UF MVG 16V 20% SMD R/TP
C139 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C140 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C142 0CE477SF6DC 470UF MVG 16V 20% R/TP(SMD)
C144 0CE106SF6DC 10UF MVG 16V 20% R/TP(SMD)
C145 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
IC101 0IPMGKE030A KIA78R05F KEC 5PIN DPAK R/T
IC102 0IMCRSJ001A SC1565IST-1.8 SEMTECH 3P SO
L103 6210TCE001G HH-1M3216-501 CERATEC 3216M
L104 6210TCE001G HH-1M3216-501 CERATEC 3216M
L105 6210TCE001G HH-1M3216-501 CERATEC 3216M
LED101 0DL233309AC SAM2333 TP KWANG GREEN/RED
Q102 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
Q103 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q106 0TR150400BA CHIP 2SA1504S(ASY) BK KEC -
R102 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R103 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R115 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R116 0RJ0102D677 10 OHM 1/10 W 5% 1608 R/TP
R121 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R122 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/T
R123 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R126 0RJ2200D677 220 OHM 1/10 W 5% 1608 R/TP
R127 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R135 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R136 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R137 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R138 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R146 0RJ3300D677 330 OHM 1/10 W 5% 1608 R/TP
C3101 0CE106VF6DC 10UF MV 16V 20% R/TP(SMD) S
C3106 0CE475VK6DC 4.7UF MV 50V 20% R/TP(SMD)
C3107 0CE106VF6DC 10UF MV 16V 20% R/TP(SMD) S
LED801 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED802 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED803 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED804 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED805 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED806 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
LED807 0DLBE0158AA BRIGHT LED ELECTRONICS BL-H
C3102 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3103 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C3104 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3108 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
L3101 6210TCE001G HH-1M3216-501 CERATEC 3216M
L3102 6210TCE001G HH-1M3216-501 CERATEC 3216M
L3103 6210TCE001G HH-1M3216-501 CERATEC 3216M
Q3101 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3102 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3103 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3104 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3105 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3106 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3107 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3215 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
Q3217 0TR387500AA CHIP 2SC3875S(ALY) BK KEC -
R3101 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3102 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3103 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3104 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
DATE: 2005. 09. 12.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R3105 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3106 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3107 0RH2200D622 220 OHM 1 / 10 W 2012 5.00%
R3108 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3109 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3110 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3111 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3112 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3113 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3114 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3115 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3116 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3117 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3118 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3119 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3120 0RH2001D622 2K OHM 1 / 10 W 2012 5.00%
R3121 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3123 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3124 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3125 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3126 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3127 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3128 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3129 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3130 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3131 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3132 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3133 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3134 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3135 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3136 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3137 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R3138 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R3139 0RH5600D622 560 OHM 1 / 10 W 2012 5.00%
R3141 0RH1001D622 1K OHM 1 / 10 W 2012 5.00%
R3145 0RH5600D622 560 OHM 1 / 10 W 2012 5.00%
R3146 0RH1000D622 100 OHM 1 / 10 W 2012 5.00%
LED3232 0DL200000CA SAM5670(DL-2LRG) BK Y-GREEN
RPE3101 6712000013A TSOP4438SO1 VISHAY 38KHZ AN
C2102 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
C2104 0CH5181K416 180PF 50V 5% NP0 2012 R/TP
C2107 0CH5101K416 100PF 50V 5% NP0 2012 R/TP
L2101 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L2102 6200JB8010L MLB-201209-1000L-N2 MAG LAY
L2103 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L2104 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
L2105 6200JB8010L MLB-201209-1000L-N2 MAG LAY
R2103 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2104 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
R2105 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2106 0RH0000D622 0 OHM 1 / 10 W 2012 5.00% D
R2107 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R2109 0RH4703D622 470K OHM 1 / 10 W 2012 5.00
R2111 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2113 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2115 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2116 0RH0472D622 47 OHM 1 / 10 W 2012 5.00%
R2117 0RH0752D622 75 OHM 1 / 10 W 2012 5.00%
R2118 0RH0822D622 82 OHM 1 / 10 W 2012 5.00%
- 45 -
LIGHT & IR ETC BOARD
SIDE BOARD
