LG 32LX2D Service Manual

- 7 -
5. Chroma & Brightness
6. Power
No Item Min Typ Max Unit Remark
1. AC Power Operating Voltage 90 264 V
2. DC Voltage, LCD Panel Drive 11.4 12.0 12.6 V
3. DC Voltage, Inverter 22.8 24.0 25.2 V
4. DC Voltage, Sound AMP 17.4 18.0 18.6 V
5. DC Voltage, Stand By 5.6 6.0 6.4 V
6. DC Voltage, Scaler(HD2) 3.1 3.3 3.5 V
7. DC Voltage, Scaler(HD2) 1.6 1.8 1.9
8. DC Voltage, ADC 3.1 3.3 3.5 V AD9883
9. DC Voltage, VCD 5 V 4.7 5 5.3 V
10. DC Voltage, VCD 3.3V 3.1 3.3 3.5 V
11. DC Voltage, Micom 4.7 5 5.3 V
12. DC Voltage, Tuner 4.75 5.00 5.25 V
DC Voltage, Tuner 31.5 33.0 34.5 V
13. DC Voltage,Video decoder IO 3.00 3.30 3.60 V
14. DC Voltage,Video decoder Core 1.35 1.50 1.65 V
15. DC Voltage, CPLD 3.00 3.30 3.60 V XC95288
16. Audio Amp, PVDD 16.20 18.00 19.80 V TAS5122
17. Audio Amp, DVDD 3.00 3.30 3.60 V TAS5122
18 PWM Modulator IO 3.00 3.30 3.60 V NSP-6241B
19 PWM Modulator Core 2.30 2.50 2.70 V NSP-6241B
No Item Min Typ Max Unit Remark
1. Brightness 300 450 cd/m
2
2. Contrast Ratio 500:1 600:1
3. Luminance Variation 1.3 %
4. Viewing Angle(Left, Right, Up, Down) 85 88 Degree
5 Color coordinate RED X Typ 0.640 Typ
Y -0.03 0.343 +0.03
GREEN X 0.280
Y 0.605
BLUE X 0.145
Y 0.065
WHITE X 0.285
(Standard) Y 0.293
6 Color Temperature Medium 8,800 9,300 9,800 OK <Test Signal>
Cool 11,000 12,000 13,000 OK Video input, 85%
Warm 6,000 6,500 7,000 OK
Full white pattern, 5MOCD
