- 8 -

7. Component Video Input (Y, PB, PR)

8. RGB, HDMI/DVI input (DTV / PC)

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed

1. 720x576 15.625 50

2. 720x576 31.25 50

3. 640x480 15.73 59.94/60

4. 704x480 31.47 59.94/60

5. 1280x720(50/60) 37.5/45.0 50/59.94/60

6. 1920x1080(50/60) 28.125/33.75 50/59.94/60.0

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed

DTV

1. 720x576 31.25 50 EDTV576p

2. 704x480 31.47 59.94 EDTV 480p

3. 1280x720(50/60) 37.5/45.0 50/59.94/60 HDTV 720p

4. 1920x1080(50/60) 28.125/33.75 50/59.94/60.0 HDTV 1080i

1. 640x350 31.468 70.09 25.17 EGA

2. 640x480 31.469 59.94 25.17 VESA(VGA)

3. 640*480 37.861 72.80 31.50 VESA(VGA)

4. 640x480 37.500 75.00 31.50 VESA(VGA)

5. 800x600 35.156 56.25 36.00 VESA(SVGA)

6. 800x600 37.879 60.31 40.00 VESA(SVGA)

7. 800x600 48.077 72.18 50.00 VESA(SVGA)

8. 800x*600 46.875 75.00 49.50 VESA(SVGA)

9. 1024x768 48.363 60.00 65.00 VESA(XGA)

10. 1024x768 56.476 70.06 75.00 VESA(XGA)

11. 1024x768 60.023 75.02 78.75 VESA(XGA)
