APPENDIX
94
APPENDIX
1111.. OOSSDD SSeelleecctt ((CCoommmmaanndd:: kk ll))
To select OSD (On Screen Display) on/off when
controlling remotely.
Data 00: OSD off
Data 01: OSD on
Transmission [k][l][ ][Set ID][ ][Data][Cr]
Acknowledgement [l][ ][Set ID][ ][OK][Data][x]
1122.. RReemmoottee CCoonnttrrooll LLoocckk//KKeeyy LLoocckk MMooddee ((CCoommmmaanndd:: kk mm))
To lock the remote control and the front panel
controls on the set.
Data 00: Lock off Data 01: Lock on
If you are not using the remote control and front
panel controls on the TV, use this mode. When main
power is on/off, remote control lock is released.
Transmission [k][m][ ][Set ID][ ][Data][Cr]
Acknowledgement [m][ ][Set ID][ ][
OK/NG][Data][x]
1133.. PPIIPP // DDWW ((CCoommmmaanndd:: kk nn))
To control the PIP (Picture In picture)/DW.
You can also control the PIP/DW using the PIP button
on the remote control or in the PIP/DW menu.
Data 00:PIP/DW off Data 01: PIP
Data 02: DW1 Data 03: DW2
Transmission [k][n][ ][Set ID][ ][Data][Cr]
Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x]
1144.. PPIIPP PPoossiittiioonn ((CCoommmmaanndd:: kk qq))
To select sub picture position for PIP.
You can also adjust the sub picture position using
PIP button on the remote control or in the PIP/DW
menu.
Data 00: Right down on screen
Data 01: Left down on screen
Data 02: Left up on screen
Data 03: Right up on screen
Transmission [k][q][ ][Set ID][ ][Data][Cr]
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
1155.. BBaallaannccee ((CCoommmmaanndd:: kk tt))
To adjust balance.
You can also adjust balance in the Audio menu.
Data Min: 00 ~ Max: 64
Refer to ‘Real data mapping 1’. See page 95.
Transmission [k][t][ ][Set ID][ ][Data][Cr]
Acknowledgement [t][ ][Set ID][ ][OK/NG][Data][x]
1100.. SShhaarrppnneessss ((CCoommmmaanndd:: kk kk))
To adjust the screen sharpness.
You can also adjust sharpness in the Picture menu.
Data Min: 00 ~ Max: 64
Refer to ‘Real data mapping 1’. See page 95.
Transmission [k][k][ ][Set ID][ ][Data][Cr]
Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x]
1166.. CCoolloorr TTeemmppeerraattuurree ((CCoommmmaanndd:: kk uu))
To adjust color temperature.
You can also adjust Color Temperature in the Picture
menu.
Data 00: Medium 01: Cool 02: Warm 03: User
Transmission [k][u][ ][Set ID][ ][Data][Cr]
Acknowledgement [u][ ][Set ID][ ][
OK/NG][Data][x]
1177.. RReedd AAddjjuussttmmeenntt ((CCoommmmaanndd:: kk vv))
To adjust red in color temperature.
Data Min: 00 ~ Max: 3C
Refer to ‘Real data mapping 2’. See page 95.
Transmission [k][v][ ][Set ID][ ][Data][Cr]
Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x]
1188.. GGrreeeenn AAddjjuussttmmeenntt ((CCoommmmaanndd:: kk ww))
To adjust green in color temperature.
Data Min: 00 ~ Max: 3C
Refer to ‘Real data mapping 2’. See page 95.
Transmission [k][w][ ][Set ID][ ][Data][Cr]
Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x]
1199.. BBlluuee AAddjjuussttmmeenntt ((CCoommmmaanndd:: kk $$))
To adjust blue in color temperature.
Data Min: 00 ~ Max: 3C
Refer to ‘Real data mapping 2’. See page 95.
Transmission [k][$][ ][Set ID][ ][Data][Cr]
Acknowledgement [$][ ][Set ID][ ][OK/NG][Data][x]
