APPENDIX
95
2200.. AAbbnnoorrmmaall SSttaattee ((CCoommmmaanndd:: kk zz))
To recognize an abnormal state.
Data FF: Read
Data 00: Normal (Power on and signal exist)
Data 01: No signal (Power on)
Data 02: Turn the TV off by remote control
Data 03: Turn the TV off by sleep time function
Data 04: Turn the TV off by RS-232C function
Data 05: 5V down
Data 06: AC down
Data 07: Turn the TV off by Fan Alarm function (option)
Data 08: Turn the TV off by Off time function
Data 09: Turn the TV off by Auto off function
Data
a: Turn the TV off by AV board detection.
* This function is “read only”.
Transmission [k][z][ ][Set ID][ ][FF][ ][Cr]
Acknowledgement [z][ ][Set ID][ ][
OK/NG][Data][x]
2211.. IISSMM MMeetthhoodd ((CCoommmmaanndd:: jj pp))
To avoid having a fixed image remain on screen.
Transmission [j][p][ ][Set ID][ ][Data][Cr]
Acknowledgement [p][ ][Set ID][ ][OK/NG][Data][x]
2222.. LLooww PPoowweerr((PPoowweerr SSaavviinngg)) ((CCoommmmaanndd:: jj qq))
To reduce the power consumption of the TV.
Data Min: 00 ~ Max: 04 (*transmit by Hexadecimal code)
Transmission [j][q][ ][Set ID][ ][Data][ ][Cr]
Acknowledgement [q][ ][Set ID][ ][OK/NG][Data][x]
2233 .. AAuuttoo CCoonnffiigguurree ((CCoommmmaanndd:: jj uu))
To adjust picture position and minimize image
shaking automatically. It works only in RGB (PC)
mode.
Data 01: To set
Transmission [j][u][ ][Set ID][ ][Data][Cr]
Acknowledgement [u][ ][Set ID][ ][
OK/NG][Data][x]
**
RReeaall ddaattaa mmaappppiinngg 11
00 : Step 0
A : Step 10
F : Step 15
10 : Step 16
64 : Step 100
6E : Step 110
73 : Step 115
74 : Step 116
C7: Step 199
FE : Step 254
FF : Step 255
**
RReeaall ddaattaa mmaappppiinngg 22
00: -30
01 : - 29
02: -28
1E: 0
28: +10
3A : +28
3B : +29
3C : +30
4E: N/A
4F: N/A
50: N/A
7 6 5 4 3 2 1 0 Function
0 0 0 1 Inversion
0 0 1 0 Orbiter
0 1 0 0 White wash
1 0 0 0 Normal
x x x x Reserved
MSB LSB
0
0 0 0 0 0 0 0
Reserved
Inversion
Orbiter
White Wash
Normal
*More two kinds of function can not be set at a time.
2244.. EEqquuaalliizzee(( CCoommmmaanndd:: jj vv ))
G To adjust equalize.
MSB LSB
0
Transmission [j][v][ ][Set ID][ ][Data][Cr]
0 0 0 0 0 0 0
Frequency Data
Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x]
Frequency
1’st Band
2’st Band
3’st Band
4’st Band
5’st Band
6’st Band
7’st Band
765
000
001
010
011
100
101
110
43210
111
8’st Band
Step
00
00
0
00
00
1
00
01
0
11
11
1
11
11
0
0(decimal)
1(decimal)
2(decimal)
...
30(decimal)
31(decimal)
