SPECIFICATION
1. Application range
This specication is applied to the LW57A chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F),
CST: 40 °C ± 5 °C
2) Relative Humidity: 65 % ± 10 %
3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
4) Specication and performance of each parts are followed
each drawing and specication by part number in accord-
ance with BOM.
5) The receiver must be operated for about 5 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE Monitor test method followed.
2) Demanded other specication
- Safety : CE, IEC specication
- EMC : CE, IEC
4. General Specication
No. Item Content Remark
1 HDMI Input (1EA) HDMI Side / support D-TV&PC
resolution
2 DVI Input (1EA) DVI
3 RGB Input(1EA) RGB-PC Analog (D-SUB 15Pin)
4 Audio Input (1EA) RGB/DVI Audio Analog L/R Input
5 Audio Output (1EA) Line out audio Analog L/R Output
6 Speaker Output ( 1EA) Compatible with Signage speaker 10W*2Ch Output@6ohms
7 IR Sensor Input (1EA) IR Sensor Detachable Type
8 External USB (2EA) Picture, Music, Movie, SVC, WiFi Device : USB Memory Stick,
WiFi Dongle
9 RS-232C Input/Output
(1EA)
Display Control 3.5ø 4pin phone Jack
10 LAN(1EA) RJ45, 100BASE-T Network Connection for Super-
Sign W/C
11 Local Key Input, MENU, ˄, ˅, <, >, AUTO/SET,Φ(Power) 8 keys
4.1. General Specication
No. Item Specication Remarks
1 Supported Sync. Type Separate Sync., Digital
2 Operating Frequency
Analog
Horizontal 30 ~ 83 kHz
Vertical 50 ~ 75 Hz
Digital
Horizontal 30 ~ 83 kHz
Vertical 50 ~ 60 Hz
3 Operating Frequency
Analog/
Digital
Max 1920×1080 @ 60 Hz
Recommend 1920×1080 @ 60 Hz
4.2. DVI-D, HDMI Specication
