41
HDMI (DTV) Support Mode
Resolution
Horizontal frequency
(kHz)
Vertical frequency (Hz)
480/60p 31.5 60
576/50p 31.25 50
720/50p 37.5 50
720/60p
45 60
1080/50i 28.1 50
1080/60i
33.75 60
1080/50p 56.25 50
1080/60p 67.5 60
NOTE
• Resolutions available for the Input Label option in RGB, HDMI/ DVI-D input modes.
- PC resolutions: 640 x 480 / 60 Hz, 1280 x 720 / 60 Hz, 1920 x 1080 / 60 Hz
- DTV resolutions: 480p, 720p, 1080p
• Vertical frequency: The product display functions by the screen image changing dozens of times every second like a
fluorescent lamp. The vertical frequency or refresh rate is the number of image displays per second. The unit is Hz.
• Horizontal frequency: The horizontal interval is the time taken to display one horizontal line. When 1 is divided by
the horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal
frequency. The unit is kHz.
