LG 37LD650H Setup Guide

10
206-4137
Side Connections Panel / RF Antenna Connection
AV IN 2
L/MONO -AUDIO- R
VIDEO
USB IN
USB IN
Insert USB device for software
updates or for picture/music
entertainment, as applicable.
Antenna
or CATV
ANTENNA IN
MP I
RF Antenna Connection
(32/37/42LD650H/LD655H/LG710H TVs)
Side Connections Panel
(All LD650H/LD655H/LG710H TVs)
VIDEO IN
Connect to video output
port on external device.
L/MONO-AUDIO-R IN
Connect to audio output
jacks on external device.
For only mono audio output,
connect to Left audio input.
A/V 2 Input
RF ANTENNA
Connect to
Antenna/Cable
input on MPI card.
MPI PORT
Connect external MPI
control devices (i.e.,
clone programmer,
PPV provider, etc.).
Note: 47/55LD650H
Antenna and MPI connec-
tions are on the rear jack
panel (see page 8).

LG 37LD650H Specifications

General

Brand	LG
Model	37LD650H
Category	LCD TV
Language	English
