LG 39LB6500 - DVI to HDMI Connection

ENG
ENGLISH
22
MAKING CONNECTIONS
AUDIO OUT
DVI OUT
VIDE
O
/
P
C
-AUDI
O
I
N
L/MONO
AU
DI
O
R
COMPONENT IN
/AV IN
IN
1
(ARC)
IN
3
(MHL)
IN
2
Y
P
P
B
B
P
P
R
R
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and
the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal,
connect an audio cable.

When using the HDMI/DVI cable, Single link is only supported.
NOTE
Choose any HDMI input port to connect.
It does not matter which port you use.
WHITE
RED
(*Not Provided)
(*Not Provided)
DVD / Blu-Ray / HD Cable Box
