LG 39LB650T Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4. General Specification
No Item Specication Remark
1. Display Screen Device 32” wide Color Display Module Resolution: 1366*768
32” wide Color Display Module Resolution: 1920*1080
39” wide Color Display Module Resolution: 1920*1080
42” wide Color Display Module Resolution: 1920*1080
47” wide Color Display Module Resolution: 1920*1080
50” wide Color Display Module Resolution: 1920*1080
55” wide Color Display Module Resolution: 1920*1080
60” wide Color Display Module Resolution: 1920*1080
70” wide Color Display Module Resolution: 1920*1080
2. Aspect Ratio 16:9 All
3. LCD Module 32" TFT WUXGA LCD
32" TFT WXGA LCD
39" TFT WXGA LCD
42" TFT WUXGA LCD
47” TFT WUXGA LCD
50” TFT WUXGA LCD
55” TFT WUXGA LCD
60” TFT WUXGA LCD
70” TFT WUXGA LCD
4. Operating Environment TFT 1) Temp. : 0 ~ 40 deg
2) Humidity : 0 ~ 85%
LGE SPEC
5. Storage Environment TFT 1) Temp. : -20 ~ 60 deg
2) Humidity : 10 ~ 90%
6. Input Voltage AC100 ~ 240V, 50/60Hz
7. Power Consumption(Max) =
LCD(Module) + Backlight(LED)
FHD
T240Hz
Slim Direct
60”’ 72.16 W LC600DUF-FGP1 [60LB720T-DA]
FHD
M120Hz
Direct
39” 45.74 W T390HVJ01.2 [39LB650T-DF]
42’’ TBD W LC420DUH-FGP2 [42LB6500-DF / 42LB650T-DF]
47’’ TBD W LC470DUH-FGP2 [47LB6500-DF / 47LB650T-DF]
50’’ 64.1 W LC500DUH-FGP2 [50LB6500-DF / 50LB650T-DF]
55’’ 62.5 W LC550DUH-FGP2 [55LB6500-DF / 55LB650T-DF]
60’’ TBD W LC600DUF-FGP2 [60LB6500-DF / 60LB650T-DF]
FHD
M120Hz
Direct M
70” 189.5 W HC700DUF-VHHD2[70LB720T-DA]
60” 71.16 W LC600DUF-FGP1[60LB720T-DA]
55” 68.2 W LC550DUH-PGF1 [55LB700T-DF/6700-DA]
47” 41.29 W LC470DUH-PGF1 [47LB700T-DF/6700-DA]
42” 38.4 W LC420DUH-PGF1 [42LB700T-DF/6700-DA]
FHD
T240Hz
Edge LED
49”’ 50.24 W FPR : LC490EUH-LGF1 [49LB870T-DA]
