5.4. 3D HDMI Input(1.4b)

No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1. 720*480p 63 59.94 / 60 54.00 F/P,L/A

31.5 27.00 T/B,S/S,S/S Full

2. 1280*720p 90.00 59.94 / 60 148.5 F/P, L/A

44.96 / 45 74.17/74.25 S/S, T&B, S/S Full

3. 1920*1080i 67.432 / 67.5 59.94 / 60 148.35/148.5 F/P, F/A

33.75 74.25 S/S, T&B, S/S Full

4. 1920*1080p 54 23.976 / 24 148.5 F/P, L/A

26.973 / 27 23.976 / 24 74.175/74.25 S/S, T&B, S/S Full

5. 1920*1080p 33.716 / 33.75 29.97 / 30.00 74.175/74.25 S/S, T&B, S/S Full

67.50 30.00 148.5 F/P, L/A

60.00 S/S, T&B

5.5. 3D HDMI-PC Input

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1. 1024*768 48.363 60.004 65.000 2D to 3D, S/S, T&B

2. 1360*768 47.712 60.015 85.500

3. 1920*1080 67.50 60.00 148.50 2D to 3D, S/S, T&B, C/B, R/I, C/I

5.6. HDMI Input(1.3)

No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1. 720*480p 63 59.94 / 60 54.00 2D to 3D, S/S, T&B, C/B, R/I, C/I

31.5 27.00

2. 1280*720p 90.00 59.94 / 60 148.5

44.96 / 45 74.17/74.25

3. 1920*1080i 67.432 / 67.5 59.94 / 60 148.35/148.5 2D to 3D, S/S, T&B

33.75 74.25

4. 1920*1080p 54 23.976 / 24 148.5 2D to 3D, S/S, T&B, C/B, R/I, C/I

26.973 / 27 23.976 / 24 74.175/74.25

5. 1920*1080p 33.716 / 33.75 29.97 / 30.00 74.175/74.25
