WIFI Built in assy feature
Block diagram
Block
diagram
34
54
Wafer
GND
GND
BT_REG_ON
3DG
WL_HOST_Wake
8pin 1.25mm
USB DP, DN
3.3V 1.2V
VCC
BCM43232
USB DP, DN
Switch
RTC6603
Antenna
2.4G/5G
RX/TX
RX/TX
Crystal
37.4MHz
Antenna
2.4G/5G
RX/TX
Switch
RTC6608O
BT TX
TX
BT
TX
Antenna
2.4G
TX
RFLPF1608
Copyright ⓒ 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
