LG 42LB650T Service Manual

- 18 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
▪ Standard color coordinate and temperature using
CA-210(CH-14) – by aging time
(1) Normal line in Korea (From January to February) : LGD
(LB5xxx, LB6xxx, LB7xxx, LB8xxx Series models)
GP4
Aging time
(Min)
Cool Medium Warm
X Y X Y X Y
271 270 286 289 313 329
1 0-2 286 295 301 314 328 354
2 3-5 284 290 299 309 326 349
3 6-9 282 287 297 306 324 346
4 10-19 279 283 294 302 321 342
5 20-35 276 278 291 297 318 337
6 36-49 274 275 289 294 316 334
7 50-79 273 272 288 291 315 331
8 80-119 272 271 287 290 314 330
9 Over 120 271 270 286 289 313 329
▪ Standard color coordinate and temperature using
CA-210(CH-14) – by aging time
(2) Normal line in Korea (From March to December) : LGD
(LB5xxx, LB6xxx, LB7xxx, LB8xxx Series models)
Normal line in Mexico : LGD (LB5xxx, LB6xxx, LB7xxx,
LB8xxx Series models)
GP4
Aging time
(Min)
Cool Medium Warm
X Y X Y X Y
271 270 286 289 313 329
1 0-2 282 289 297 308 324 348
2 3-5 281 287 296 306 323 346
3 6-9 279 284 294 303 321 343
4 10-19 277 280 292 299 319 339
5 20-35 275 277 290 296 317 336
6 36-49 274 274 289 293 316 333
7 50-79 273 272 288 291 315 331
8 80-119 272 271 287 290 314 330
9 Over 120 271 270 286 289 313 329
(3) O/S Module(AUO, INX, Sharp, CSOT, BOE)
cool med warm
x y x y x y
spec 271 270 286 289 313 329
target 278 280 293 299 320 339
5.2. Option selection per country
5.2.1. Overview
(1) Tool option selection is only done for models in Non-USA
North America due to rating
(2) Applied model: LA42B Chassis applied to CANADA and
MEXICO
5.2.2. Country Group selection
(1) Press ADJ key on the Adj. R/C, and then select Country
Group Menu
(2) Depending on destination, select US, then on the lower
Country option, select US, CA, MX.
Selection is done using +, - KEY
5.2.3. Tool Option inspection
▪ Press Adj. key on the Adj. R/C, then select Tool option
Model Tool 1 Tool 2 Tool 3 Tool 4 Tool 5 Tool 6 Tool 7 Area
65LB7100-
UC
33641 4114 25475 64582 43686 2426 33579 22282
65LB7100-
UB
33641 4114 25475 64582 43686 2426 33579 22282
70LB7100-
UC
39786 4114 25475 64582 43686 2394 43819 22282
60LB7100-
UT
33640 4114 25475 64582 43686 2394 35627 22282
55LB7200-
UB
134 4114 25475 64582 48038 2394 39723 22282
42LB6500-
UM(AUO)
4258 4370 33667 64582 2726 2474 47915 22282
42LB6500-
UM(LGD)
162 4370 33667 64582 11174 2474 47915 22282
47LB6500-
UM
22282
50LB6500-
UM
165 4370 33667 64582 11174 2426 47915 22282
55LB6500-
UM
166 4370 33155 64582 11174 2394 47915 22282
60LB6500-
UP
22282
42LB6300-
UQ
22282
47LB6300-
UQ
259 4379 33155 64582 9126 2427 47915 22282
55LB6300-
UQ
22282
60LB6300-
US
22282
65LB6300-
UA
22282
55LB8700-
UA
70 4627 25236 64774 43434 2377 33291 22282
* Tool option can be reconstructed by Software
