LG 42PC1R Series Service Manual

- 29 -
120 6400WMCX03A SPEAKER, WOOFER G1560102 MACOM WOOFER 8OHM 15/20W 82DB OTHERS 100HZ 193*57MM
121 6400DTTX02B SPEAKER, TWEETER EN15D-6659 TOPTONE TWEETER(DOME) 8OHM 15/20W 78DB OTHERS PC1 MODEL
6400DTTX02C Speaker, Tweeter EN15D-6659-1 N35 15W 8OHM 81DB - 38.3X88mM LUG ALRLLH(RUSSIA)
200 6348Q-E066H PDP, Module-XGA PDP42X30201.AKLGG XGA 42INCH 1024X768 16/9 ALRLLH(RUSSIA)
6348Q-E128J PDP, 42 1024*768 PDP42X30201.ADLGB
201 6871QCH077A PWB(PCB) ASSEMBLY, DISPLAY CTRL ASSY HAND INSERT 42HD 42X3 CTRL ASSY HAND
202 6871QDH117A PWB(PCB) ASSEMBLY, DISPLAY YDRV ASSY HAND INSERT 42HD 42X3 YDRV HAND INSERT
203 6871QLH059A PWB(PCB) ASSEMBLY, DISPLAY XRLT ASSY HAND INSERT 42HD 42X3 XRLT ASSY HAND
204 6871QRH068A PWB(PCB) ASSEMBLY, DISPLAY XRRT ASSY HAND INSERT 42HD 42X3 XRRT ASSY
205 6871QYH053B PWB(PCB) ASSEMBLY, DISPLAY YSUS ASSY HAND INSERT 42HD 42X3 VER.B
206 6871QZH056B PWB(PCB) ASSEMBLY, DISPLAY ZSUS ASSY HAND INSERT 42HD 42X3 VER.B
240 4980900109A Supporter, COMPLEX ASSY AL 42PC1R-TA, VERTICAL RIGHT ALRLLH(RUSSIA)
4980900109C SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL RIGHT, C/SKD
250 4980900109B Supporter, COMPLEX ASSY AL 42PC1R-TA, VERTICAL LEFT ALRLLH(RUSSIA)
4980900109D SUPPORTER, ASSY AL 42PC1R-TA, VERTICAL LEFT, C/SKD
300 30919E0024C Cover Assembly, 42PC1R-ZH BRAND 30909E0008A 3211900003A(LG) ALRLLH(RUSSIA)
30919E0024Q CABINET ASSEMBLY, 42PC1R-ZH BRAND 30909E0008 3211900003A C/SKD
301 4980900113A Supporter, COMPLEX ASSY AL FILTER TOP 42PC1R-TA ALRLLH(RUSSIA)
4980900113B SUPPORTER, ASSY AL FILTER TOP 42PC1R-TA C/SKD
302 4980900114A Supporter, COMPLEX ASSY AL FILTER BOTTOM 42PC1R-TA ALRLLH(RUSSIA)
4980900114B SUPPORTER, ASSY AL FILTER BOTTOM 42PC1R-TA C/SKD
303 4980900115A Supporter, COMPLEX ASSY AL FILTER RIGHT 42PC1R-TA ALRLLH(RUSSIA)
4980900115B SUPPORTER, ASSY AL FILTER RIGHT 42PC1R-TA, C/SKD
304 4980900116A Supporter, COMPLEX ASSY AL FILTER LEFT 42PC1-TA ALRLLH(RUSSIA)
4980900116B SUPPORTER, ASSY AL FILTER LEFT 42PC1-TA, C/SKD
400 3809900103A Cover Assembly, 42PC1R NON ANALOG ALRLLH(RUSSIA)
3809900103P BACK COVER ASSEMBLY, 42PC1 NON LGEMA ASSY ONLY (ANALOG)
430 3501900014A Base Assembly, D/T SPK STAND AP-42DC11 MF056A FOLDING STAND ALRLLH(RUSSIA)
3501900014C BOARD ASSEMBLY, D/T SPK STAND AP-42DC11 MF056A FOLDING STAND LGERS C/SKD
501 3301900095B PLATE ASSEMBLY, AV 3301900098A 3300900017B(PRESS) 42PC CORTEZ-A
3301900095P PLATE ASSEMBLY, AV 3301900098A 3300900017H(PRESS) H3 C/SKD 42PC1R-ZH.KETLLMP
502 3301900094A PLATE ASSEMBLY, ASSY 3300900010B CORTEZ-A PDP PC SERIES COMMON
3301900094F PLATE ASSEMBLY, ASSY 3300900010G VCTP PDP PC SERIES CORTEZ-A, EU, 42PC1R-ZH.KETLLMP C/SKD
520 68719MMU02A PWB(PCB) ASSEMBLY, MAIN MAIN1 M.I PP62A 42PC1R . H3-CORTEZ
68719MMX35A PWB(PCB) ASSEMBLY, MAIN MAIN1 M.I PP62A 42PC1R-ZH KETLLMP CKD MANUAL INSERT FOR CKD
560 6719SMH44A PWB(PCB) ASSEMBLY, SUB SUB M.I PP62A 42PC1R AMLLKX CLTR
68719SMM72A PWB(PCB) ASSEMBLY, SUB SUB M.I PP62A 42PC1R-ZH KETLLMP LOCAL-KEY CTRL MANUAL CKD LGEMA
570 68719SMH46A PCB Assembly, Sub SUB M.I PP62A 42PC1R ATLLKR H3 PREAMP ALRLLH(RUSSIA)
68719SML93A PWB(PCB) ASSEMBLY, SUB SUB M.I PP62A 42PC1R-ZH SETLLJP DMS SKD PREAM
68719SMM71A PWB(PCB) ASSEMBLY, SUB SUB M.I PP62A 42PC1R-ZH KETLLMP PREAMP MANUAL CKD FOR LGEMA
580 6709900019A POWER SUPPLY ASSEMBLY, 42INCH UNIFICATION PSU PDP LGIT PA61B 400W 42PB2D
600 68719SML49A PCB Assembly, Sub SUB M.I PP62A 42PC1R-ZH AEULLAX H3H SIDE A/V ALRLLH(RUSSIA)
68719SML91A PWB(PCB) ASSEMBLY,SUB SUB M.I PP62A 42PC1R-ZH SETLLJ DMS SKD SIDE A/V
68719SMM70A PWB(PCB) ASSEMBLY, SUB SUB M.I PP62A 42PC1R-ZH KETLLMP SIDE A/V MANUAL CKD FOR LGEMA
601 4811900021C BRACKET ASSEMBLY, SIDE AV 42PC1R-ZH PP62A CORTEZ-A, E
602 48149V0003A SHIELD, SIDE AV 42PC1R
EXPLODED VIEW PARTS LIST
No. Part No. Descriptions
The components identified by mark is
critical for safety.
Replace only with part number specified.
