If the S-VIDEO(Y/C) signal is received through the Euro scart socket 2 (AV2), you must change to
the S-Video2 mode.
GG
If you want to use the EURO scart cable, you have to use the signal shielded Euro scart cable.
GG
If both S-Video and VIDEO sockets have been connected to the S-VHS VCR simultaneousiy.
only the S-Video can be received.
NOTE
1
1
2
Connect the Euro scart socket of the VCR to the
AAVV11
Euro scart socket on the set.
Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
Select
AAVV11
input source with using the
IINNPPUUTT
button on
the remote control.
- If connected to
AAVV22
Euro scart socket, select
AAVV22
input source.
1
2
3
Connect the S-VIDEO output of the VCR to the
SS--VViiddeeoo
input on the set. The picture quality is
improved; compared to normal composite (RCA cable) input.
Connect the audio outputs of the VCR to the
AAUUDDIIOO
input jacks on the set.
Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
Select
AAVV33
input source with using the
IINNPPUUTT
button
on the remote control.
1
2
4
3
When connecting with a Euro Scart
When connecting with an S-Video cable
