DDiiggiittaall SSeett--ttoopp BBooxx
DDiiggiittaall SSeett--ttoopp BBooxx
GG
TV can receive the video and audio signal simultaneously with using a HDMI cable.
GG
If the digital set-top box supports Auto HDMI function, output resolution of the digital set-top box
will be automatically set to 1280x720p.
GG
If the digital set-top box does not support Auto HDMI, you need to set the output resolution
appropriately. To get the best picture quality, adjust the output resolution of the digital
set-top box to 1280x720p.
1
2
1
When connecting with a D-sub 15 pin cable
Connect the RGB output of the digital set-top box to
the
RRGGBB IINN ((PPCC//DDTTVV))
jack on the set.
Connect the audio outputs of the set-top box to the
AAUUDDIIOO ((RRGGBB//DDVVII))
jack on the set.
Turn on the digital set-top box. (Refer to the owner’s
manual for the digital set-top box.)
Select
RRGGBB--DDTTVV
input source with using the
IINNPPUUTT
button on the remote control.
1
2
3
4
When connecting with a HDMI cable
Connect the HDMI output of the digital set-top box to
the
HHDDMMII ((
or
HHDDMMII//DDVVII)) IINN
jack on the set.
Select
HHDDMMII11//DDVVII
or
HHDDMMII22((
or
HHDDMMII//DDVVII))
input
source with using the
IINNPPUUTT
button on the remote control.
Turn on the digital set-top box. (Refer to the owner’s
manual for the digital set-top box.)
1
2
3
