LG 42PC35 - Page 38

IC506 0ISS455880A KA4558D 12TO22V 6mV - 0W 400MW 76
IC507 0IPMGKE030A KIA78R05F 6TO12V 5V 8W DPAK R/TP
IC600 0IPRP00602A TPS2010ADR 2.7TO5.5V 8.6MSEC 3.4M
IC700 EAN33595901 FLI8548H-LF-BE 300MVTO3.6V,300MVT
IC701 0IMP242560A 24LC256T-I/SM 256KBIT 256KX8BIT 2
IC702 EAN34099701 M2404HEPROM 4KBIT 512 x 8bit 2.5V
IC801 0IMMRIH038B HYB25D(C)256160CE-5 256MBIT 4MX16
IC804 0IPMG78391A SC2595STR 2.3TO5V 0 0W SOIC R/TP
IC900 0IPMGFA061A FAN1587AD33X 4.8TO10.3V 3.3V 0W T
IC901 0IPMGFA061A FAN1587AD33X 4.8TO10.3V 3.3V 0W T
IC902 0IPMG00107A AZ1117H-2.5TR/E1 15V 2.5V 0W SOT2
IC903 0IPMG00027A SC156515M-1.8TR 2.2TO5.5V 1.8V 0W
IC904 EAN32662801 KA7809ERTM 35V to 40V 9V 1W DPAK
F1 6210VH0004A Filter, 6210VH0004A 100OHM 30MM 13MM 34MM
F2 6210VH0004A Filter, 6210VH0004A 100OHM 30MM 13MM 34MM
F3 6210VH0004A Filter, 6210VH0004A 100OHM 30MM 13MM 34MM
L100 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L101 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L102 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L103 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L104 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L105 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L106 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L108 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1101 6210TCE001L Filter, HB-1T2012-102JT 1000OHM 2X1.25X1M
L1102 6210TCE001L Filter, HB-1T2012-102JT 1000OHM 2X1.25X1M
L1104 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1105 6210TCE001P Filter, HB-1S2012-121JT(H:1mm) 120OHM 2X1
L1106 6210TCE001P Filter, HB-1S2012-121JT(H:1mm) 120OHM 2X1
L1107 6210TCE001P Filter, HB-1S2012-121JT(H:1mm) 120OHM 2X1
L1108 6210TCE001P Filter, HB-1S2012-121JT(H:1mm) 120OHM 2X1
L1109 6210TCE001P Filter, HB-1S2012-121JT(H:1mm) 120OHM 2X1
L1206 6210TCE001Z Filter, HH-1M2012-600JT 60OHM 2X1.25X1MM
L1207 6210TCE001Z Filter, HH-1M2012-600JT 60OHM 2X1.25X1MM
L1208 6210TCE001Z Filter, HH-1M2012-600JT 60OHM 2X1.25X1MM
L1211 6210TCE001L Filter, HB-1T2012-102JT 1000OHM 2X1.25X1M
L1212 6210TCE001L Filter, HB-1T2012-102JT 1000OHM 2X1.25X1M
L1300 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1301 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1302 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1303 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1309 6210TCE001S Filter, HU-1M2012-121 120OHM 2X1.25X1MM S
L1310 6210TCE001S Filter, HU-1M2012-121 120OHM 2X1.25X1MM S
L1311 6210TCE001S Filter, HU-1M2012-121 120OHM 2X1.25X1MM S
L1312 6210TCE001S Filter, HU-1M2012-121 120OHM 2X1.25X1MM S
L1314 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1315 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1401 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1403 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L1412 6210TCE001E Filter, HB-1M2012-800JT(H:1mm) 80OHM 2X1.
L1413 6210TCE001E Filter, HB-1M2012-800JT(H:1mm) 80OHM 2X1.
L400 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L606 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L607 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L700 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L701 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L703 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L704 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L705 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L706 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L707 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L900 6210TCE001X Filter, HU-1H4532-121JT 120OHM 4.5X3.2X1.
L907 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L909 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L911 6210TCE001X Filter, HU-1H4532-121JT 120OHM 4.5X3.2X1.
L912 6210TCE001X Filter, HU-1H4532-121JT 120OHM 4.5X3.2X1.
L913 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L918 6210TCE001X Filter, HU-1H4532-121JT 120OHM 4.5X3.2X1.
L919 6210TCE001X Filter, HU-1H4532-121JT 120OHM 4.5X3.2X1.
L923 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L925 6210TCE001G Filter, HH-1M3216-501JT 500OHM 3.2X1.6X1.
L101 0LC1032101A Inductor, FI-C3216-103KJT 10UH 10% - 50MA 0
L109 0LC1032101A Inductor, FI-C3216-103KJT 10UH 10% - 50MA 0
L1209 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1210 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1213 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1214 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1216 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1217 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1221 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1222 0LCML00020G Inductor, MLI-201209-3R3K 3.3UH 10% 0V 30MA
L1304 EAP32842806 Inductor, NR8040T220M 22UH 20% 250V 2.2A 0.
L1305 EAP32842806 Inductor, NR8040T220M 22UH 20% 250V 2.2A 0.
L1306 EAP32842806 Inductor, NR8040T220M 22UH 20% 250V 2.2A 0.
L1307 EAP32842806 Inductor, NR8040T220M 22UH 20% 250V 2.2A 0.
L600 0LCTA00003A Inductor, LEMC3225T6R8M 6.8UH 20% 50V 360MA
L601 0LCTA00003A Inductor, LEMC3225T6R8M 6.8UH 20% 50V 360MA
L604 0LC0233002A Inductor, FI-B2012-332KJT 3.3UH 10% 50V 50M
L605 0LCTA00003A Inductor, LEMC3225T6R8M 6.8UH 20% 50V 360MA
Q101 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q102 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q103 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1100 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1200 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1201 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1202 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1203 0TR102009AM KRA102S PNP -30V 0V -50V -0.1A -0
Q1204 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1300 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1301 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1302 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1303 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1304 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50V 150M
Q1305 0TR102009AM KRA102S PNP -30V 0V -50V -0.1A -0
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
- 38 -
LGE Internal Use OnlyCopyright©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
FILTERs & INDUCTORs
TRANSISTORs & FETs
