LG 42PC51 - Page 33

- 33 -
R248 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R249 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R250 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R251 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R252 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R253 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R254 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R255 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R265 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10W 1608
R266 0RJ6801D677 MCR03EZPJ682 6.8KOHM 5% 1/10W 160
R267 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/10W 160
R268 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10W 1608
R269 0RJ6801D677 MCR03EZPJ682 6.8KOHM 5% 1/10W 160
R270 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/10W 160
R271 0RJ1502D677 MCR03EZPJ153 15KOHM 5% 1/10W 1608
R272 0RJ6801D677 MCR03EZPJ682 6.8KOHM 5% 1/10W 160
R273 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/10W 160
R3 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R3 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R300 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R301 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R302 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10W 1608
R303 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10W 1608
R304 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R305 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R306 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R307 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R308 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W 1608
R310 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10W 1608
R311 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10W 1608
R312 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R313 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R314 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R315 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R316 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R317 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R318 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R319 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R320 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R321 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R322 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R323 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R324 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R325 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R326 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R327 0RJ0122D677 MCR03EZPJ120 12OHM 5% 1/10W 1608
R328 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W 1608
R329 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W 1608
R330 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R331 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R332 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R333 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R334 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R335 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R336 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R337 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W 1608
R338 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R338 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W 1608
R339 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R339 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W 1608
R340 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R340 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W 1608
R341 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R342 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R344 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R345 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W 1608
R346 0RJ1004D677 MCR03EZPJ105 1MOHM 5% 1/10W 1608
R347 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10W 1608
R349 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R350 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R352 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R353 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R354 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R355 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R356 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R358 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R359 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W 1608
R361 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W 1608
R362 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R363 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R364 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W 1608
R365 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R366 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R367 0RJ0392D677 MCR03EZPJ390 39OHM 5% 1/10W 1608
R368 0RJ0392D677 MCR03EZPJ390 39OHM 5% 1/10W 1608
R369 0RJ0392D677 MCR03EZPJ390 39OHM 5% 1/10W 1608
R370 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R371 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R4 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R4 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R401 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10W 1608
R402 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10W 1608
R404 0RJ7501D677 MCR03EZPJ752 7.5KOHM 5% 1/10W 160
R405 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10W 160
R407 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R408 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W 1608
R410 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W 1608
R411 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W 1608
R412 0RJ0822D677 MCR03EZPJ820 82OHM 5% 1/10W 1608
R413 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10W 1608
R421 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R422 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10W 1608
R423 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W 1608
R423 0RJ1800D677 MCR03EZPJ181 180OHM 5% 1/10W 1608
R424 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1608 R
R5 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R5 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2012 R/
R503 0RJ2000D477 MCR03EZPF201 200OHM 1% 1/10W 1608
R504 0RJ1500D677 MCR03EZPJ151 150OHM 5% 1/10W 1608
R505 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W 1608
LOC. NO. PART NO. DESCRIPTION / SPECIFICATION LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
