- 11 -
13. Default Value in Adjustment mode
13-1. Auto Color Balance
13-2. Write Balance
14. EEPROM Data Write
(Serial No D/L)
14-1. Signal TABLE
CMD : A0h
LENGTH : 85~94h (1~16 bytes)
ADH : E
2
PROM Sub Address high (00~1F)
ADL : E
2
PROM Sub Address low (00~FF)
Data : Write data
CS :
CMD + LENGTH + ADH + ADL + Data_1 + ... + Data_n
Delay : 20ms
14-2. Command Set
* Description
FOS Default write : <7mode data> write
Vtotal, V_Frequency, Sync_Polarity, Htotal, Hstart, Vstart, 0, Phase
Data write : Model Name and Serial Number write in EEPROM,.
14-3. Method & Notice
(1) Serial number D/L is using of scan equipment.
(2) Setting of scan equipment operated by Manufacturing
Technology Group.
(3) Serial number D/L must be conformed when it is produced
in production line, because serial number D/L is mandatory
by D-book 4.0.
15. Set Information(Serial No& Model name)
15-1. Setting up like bottom figure
(After setting white balance, this is set)
(Setting: Press ADJ Key in the Adjust remocon)
(1) Select “System Control 2” by using
D / E (CH+/-) key, and
press
V (ENTER) Using Adjust remocon, RS-232 Host &
Baud Rate & Download value change)
15-2. Push the menu button in DTV mode.
(1) Select the STATION-> Diagno stics -> To set.
CMD LENGTH ADH ADL DATA_1 DATA_n ... CS DELAY
Model
Name
42PC55-ZB
50PC55-ZB
50PB65-ZA
Tool
Option1
2048
2052
2244
1697
1953
1977
0
0
0
14
14
14
2
2
2
1
1
1
192
192
192
Tool
Option2
Area
Option
Option1 Option2 Option3 Option3
No
1
EEPROM WRITE A0h 84h+n n-byted Write
(n=1~16)
Adjust mode CMD(hex) LENGTH(hex) Description
(Fig. 7) Default on OSD
<Component> <RGB>
<AV>
(Fig. 8) Default on OSD
