LG 42PG1000 User Manual

- 4 -
LGE Internal Use OnlyCopyright©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
SPECIFICATIONS
NOTE : Specifications and others are subject to change without notice for improvement .
V Application Range
This spec is applied to the 42” PLASMA TV used PD83A Chassis.
V Specification
Each part is tested as below without special appointment.
1) Temperature : 25±5°C (77±9°F), CST : 40±5
2) Relative Humidity: 65±10%
3) Power Voltage: Standard Input voltage (100-240V~, 50/60Hz)
* Standard Voltage of each product is marked by models.
4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with SBOM.
5) The receiver must be operated for about 20 minutes prior to the adjustment.
V Test Method
1) Performance : LGE TV test method followed.
2) Demanded other specification
Safety : CE, IEC specification
EMC : CE, IEC
V General Specification ( 42”XGA )
Chassis
PD83A 42PG1000 Austria,Belgium,Bulgaria,Coratia,Czech,Denmark,Finland,
France,Germany,Greece,Hungary,Italy,Luxembourg,
Netherlands,Norway,Poland,Portugal,Rumania,Russia,Ser
bia,Slovenia,Spain,Sweden,Switzerland,UK
LG
Model Name Market Brand Remark
Display Screen Device
Aspect Ratio
PDP Module
Operating Environment
Storage Environment
Input Voltage
1
2
3
4
5
6
No Item Specification Remark
42” Wide Color Display Module
16:9
PDP42XG,
RGB Closed Type, Film Filter
1)Temp. : 0~40deg
2)Humidity : 20~80%
3)Temp. : -20~60deg
4)Humidity : 10~90%
100-240V~, 50/60Hz
Plasma Display Panel
LGE SPEC.
Maker : LG
42PG1000-ZA Safety : IEC/EN60065
EMI : EN55013
EMS : EN55020
Austria,Belgium,Bulgaria,Coratia,Czech,Denmark,Finland
,France,Germany,Greece,Hungary,Italy,Luxembourg,
Netherlands,Norway,Poland,Portugal,Rumania,Russia,
Serbia,Slovenia,Spain,Sweden,Switzerland,UK
Model ApplianceMarket Remark

LG 42PG1000 Specifications

General

Depth	83.6 mm
Height	677 mm
Weight	24000 g
Pixel pitch	0 mm
Aspect ratio	16:9
Audio system	SRS TruSurround XT
Product color	Black
LED indicators	Stand-by
RMS rated power	14 W
Display diagonal	42 \
Depth (with stand)	308 mm
Display brightness	1500 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Width (with stand)	1040 mm
Height (with stand)	731 mm
Weight (with stand)	26000 g
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Contrast ratio (dynamic)	30000:1
Contrast ratio (typical)	-
Analog signal format system	PAL, SECAM
Power consumption (standby)	0.8 W
Power consumption (typical)	310 W
