LG 42PG20 - Introduction and Overview; Outline of Topics to be Discussed

2
Plasma Fall 2008 42PG20
Overview of Topics to be Discussed
• UNIFIED Y and Z SUS Board (Z SUS Drive signals developed)
• Z SUS Output Board (Receives Z SUS signals from Y-SUS PWB)
• Y Drive Boards (Receives Y Drive signals from Y-SUS PWB)
• Control Board (Outputs Y and Z control signals to Y SUS PWB)
• X Drive Boards (2)
Circuit Board Operation, Troubleshooting and Alignment of :
• Switch mode Power Supply
• Main Board
Section 1
Section 2
Contact Information, Preliminary Matters, Specifications,
Plasma Overview, General Troubleshooting Steps,
Disassembly Instructions, Voltage and Signal Distribution
OUTLINE
OUTLINE
NEW
NEW
NEW
