LG 42PG3000 User Manual

- 21 -
LGE Internal Use OnlyCopyright©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
(6) In the case of becomes unusual display from HDMI mode
(7) In the case of becomes unusual display from SCART1 mode
(8) In the case of becomes unusual display from SCART2 mode
Is the Video input of the
HDMI Jack normal?
Is the TDMS(IC902)
normal?
Yes
Yes
Same as Block A
Check the input source
No
No
Is the Video input od A/V
Jack(JK601) normal?
Yes
Same as Block A
Check the input source
No
Is the Video input od A/V
Jack(J600) normal?
Yes
Same as Block A
Check the input source
No
Is the Input and Output signal,IIC
Communication normal?
Replace the IC.
No

LG 42PG3000 Specifications

General

Comb filter	2D
Pixel pitch	0 mm
Aspect ratio	16:9
Audio system	SRS TruSurround XT
Certification	RoHS, UL
Product color	Black
Response time	0.001 ms
Package weight	35000 g
Noise reduction	Yes
RMS rated power	20 W
Display diagonal	42 \
Depth (with stand)	308 mm
Display brightness	1500 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	100-240V, 50/60 Hz
Width (with stand)	1040 mm
HDMI ports quantity	3
Height (with stand)	727.1 mm
Weight (with stand)	28500 g
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Contrast ratio (typical)	-
Power consumption (standby)	0.8 W
Power consumption (typical)	310 W
