LG 42PG3000 User Manual

- 4 -
LGE Internal Use OnlyCopyright©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
SPECIFICATIONS
NOTE : Specifications and others are subject to change without notice for improvement .
V Application Range
This spec is applied to the 50” PLASMA TV used PD83A Chassis.
V Specification
Each part is tested as below without special appointment.
1) Temperature : 25±5°C (77±9°F), CST : 40±5
2) Relative Humidity: 65±10%
3) Power Voltage: Standard Input voltage (100-240V~, 50/60Hz)
* Standard Voltage of each product is marked by models.
4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with SBOM.
5) The receiver must be operated for about 20 minutes prior to the adjustment.
V Test Method
1) Performance : LGE TV test method followed.
2) Demanded other specification
Safety : CE, IEC specification
EMC : CE, IEC
V Module Specification
(1) 42”
Display Screen Device
Aspect Ratio
PDP Module
Operating Environment
Storage Environment
Input Voltage
1
2
3
4
5
6
No Item Specification Remark
42 inch Wide Color Display Module
16:9
PDP42XG####,
RGB Closed Type, Film Filter
1)Temp. : 0~40deg
2)Humidity : 20~80%
3)Temp. : -20~60deg
4)Humidity : 10~90%
100-240V~, 50/60Hz
PDP
LGE SPEC.
Maker LG
Chassis
PD83A 42PG10/20/3000
50PG10/20/3000
60PG3000
UK, German, Italy, France, Sweden, Finland, Spain,
Netherlands, Belgium, Luxembourg, Greece, Denmark,
Czech, Austria, Poland, Portugal, Norway, Rumania,
Hungary, Bulgaria,Coratia, Serbia, Swiss, Slovenia,
Russia
LG
Model Name Market Brand Remark
42PG10/20/3000
50PG10/20/3000
60PG3000
Safety : IEC/EN60065
EMI : EN55013
EMS : EN55020
UK, German, Italy, France, Sweden, Finland, Spain,
Netherlands, Belgium, Luxembourg, Greece, Denmark,
Czech, Austria, Poland, Portugal, Norway, Rumania,
Hungary, Bulgaria,Coratia, Serbia, Swiss, Slovenia,
Russia
Model ApplianceMarket
TEST
Remark

LG 42PG3000 Specifications

General

Comb filter	2D
Pixel pitch	0 mm
Aspect ratio	16:9
Audio system	SRS TruSurround XT
Certification	RoHS, UL
Product color	Black
Response time	0.001 ms
Package weight	35000 g
Noise reduction	Yes
RMS rated power	20 W
Display diagonal	42 \
Depth (with stand)	308 mm
Display brightness	1500 cd/m²
Display resolution	1024 x 768 pixels
Display technology	Plasma
Power requirements	100-240V, 50/60 Hz
Width (with stand)	1040 mm
HDMI ports quantity	3
Height (with stand)	727.1 mm
Weight (with stand)	28500 g
SCART ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Contrast ratio (typical)	-
Power consumption (standby)	0.8 W
Power consumption (typical)	310 W
