5. External input format
5.1. 2D Mode
5.1.1. Component input(Y, CB/PB, CR/PR)
5.1.2. HDMI Input (PC/DTV)
No
Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1 720*480 15.73 60 13.5135 SDTV ,DVD 480I
2 720*480 15.73 59.94 13.5 SDTV ,DVD 480I
3 720*480 31.50 60 27.027 SDTV 480P
4 720*480 31.47 59.94 27.0 SDTV 480P
5 1280*720 45.00 60.00 74.25 HDTV 720P
6 1280*720 44.96 59.94 74.176 HDTV 720P
7 1920*1080 33.75 60.00 74.25 HDTV 1080I
8 1920*1080 33.72 59.94 74.176 HDTV 1080I
9 1920*1080 67.500 60 148.50 HDTV 1080P
10 1920*1080 67.432 59.94 148.352 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed
HDMI-PC DDC
1 640*350 31.46 70.09 25.17 EGA Х
2 720*400 31.46 70.08 28.32 DOS O
3 640*480 31.46 59.94 25.17 VESA(VGA) O
4 800*600 37.87 60.31 40.00 VESA(SVGA) O
5 1024*768 48.36 60.00 65.00 VESA(XGA) O
6 1152*864 54.34 60.05 80.00 VESA O
7 1280*1024 63.98 60.02 108.00 VESA (SXGA) O
8 1360*768 47.71 60.01 85.50 VESA (WXGA) O
9 1920*1080 67.5 60 148.5
WUXGA(Reduced Blanking)
O
10 3840*2160 67.5 30 297.00
Only UD Model
O
11 3840*2160 56.25 25.00 297.00
Only UD Model
O
12 3840*2160 54 24 297.00
Only UD Model
O
13 4096*2160 53.95 23.97 297
Only UD Model
O
14 4096*2160 54 24 297 Only UD Model O
