LG 43UM7500PLA User Manual

8
ENGLISH
Connections
Connect various external devices to the TV and switch input modes to
select an external device. For more information of external device’s
connection, refer to the manual provided with each device.
Antenna/Cable
Connect the TV to a wall antenna socket with an RF cable (75 Ω).
• Use a signal splitter to use more than 2 TVs.
• If the image quality is poor, install a signal amplier properly to
improve the image quality.
• If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.
• An antenna cable and converter are not supplied.
• For a location that is not supported with ULTRA HD broadcasting,
this TV cannot receive ULTRA HD broadcasts directly.
Satellite dish
Connect the TV to a satellite dish to a satellite socket with a satellite RF
cable (75 Ω). (Depending on model)
CI module
View the encrypted (pay) services in digital TV mode. (Depending on
model)
• Check if the CI module is inserted into the PCMCIA card slot in the
right direction. If the module is not inserted properly, this can
cause damage to the TV and the PCMCIA card slot.
• If the TV does not display any video and audio when CI+ CAM is
connected, please contact to the Terrestrial/Cable/Satellite Service
Operator.
Other connections
Connect your TV to external devices. For the best picture and audio
quality, connect the external device and the TV with the HDMI cable.
Some separate cable is not provided.
HDMI
• Supported HDMI Audio format:
(Depending on model)
DTS (44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz),
DTS HD (44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192
kHz),
True HD (48 kHz),
Dolby Digital / Dolby Digital Plus (32 kHz / 44.1 kHz / 48 kHz),
PCM (32 kHz / 44.1 kHz / 48 kHz / 96 kHz / 192 kHz)
(Only UHD models)
• ( ) [Picture] [Additional Settings] [HDMI
ULTRA HD Deep Colour]
- On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0)
- O : Support 4K @ 50/60 Hz 8 bit (4:2:0)
If the device connected to Input Port also supports ULTRA HD Deep
Colour, your picture may be clearer. However, if the device doesn’t
support it, it may not work properly. In that case, change the TV’s
[HDMI ULTRA HD Deep Colour] setting to o.
USB
Some USB Hubs may not work. If a USB device connected using a USB
Hub is not detected, connect it to the USB port on the TV directly.

LG 43UM7500PLA Specifications

General

Color depth	10 bit
Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Motion interpolation technology	-
PC in (D-Sub)	No
HDMI ports quantity	3
Common interface (CI)	Yes
USB 2.0 ports quantity	2
S-Video inputs quantity	0
Digital audio optical out	1
Common interface Plus (CI+) version	1.4
Package depth	152 mm
Package width	1060 mm
Package height	660 mm
Package weight	11200 g
App store	LG Content Store
Luminance	65 %
Google applications	Google Play
Annual energy consumption	98 kWh
Network streaming services supported	YouTube
Tuner type	Digital
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Music apps	Spotify
Video apps	Amazon Prime Video, Netflix
Operating system version	4.5
Operating system installed	Web OS
Audio formats supported	AAC, AC3, AC4, DTS, EAC3, HE-AAC, MP2, PCM
Video formats supported	H.265, HEVC
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	200 x 200 mm
Remote control type	MR19
Audio decoders	DTS, Dolby Digital
RMS rated power	20 W
Power consumption (standby)	0.5 W
Power consumption (typical)	71 W

Weight and Dimensions

Depth (with stand)	216 mm
Height (with stand)	625 mm
Weight (with stand)	9100 g
Depth (without stand)	86.4 mm
Width (without stand)	975 mm
Height (without stand)	571 mm
Weight (without stand)	9000 g
