7. HDMI Input

7.1. DTV mode

No. Resolution H-freq(kHz) V-freq.(kHz) Proposed

1. 640*480 31.469 / 31.5 59.94/60 SDTV 480P

2. 720*480 31.469 / 31.5 59.94 / 60 SDTV 480P

3. 720*576 31.25 50 SDTV 576P

4. 720*576 15.625 50 SDTV 576I

5. 1280*720 37.500 50 HDTV 720P

6. 1280*720 44.96 / 45 59.94 / 60 HDTV 720P

7. 1920*1080 33.72 / 33.75 59.94 / 60 HDTV 1080I

8. 1920*1080 28.125 50.00 HDTV 1080I

9. 1920*1080 26.97 / 27 23.97 / 24 HDTV 1080P

10. 1920*1080 25 HDTV 1080P

11. 1920*1080 33.716 / 33.75 29.976 / 30.00 HDTV 1080P

12. 1920*1080 56.250 50 HDTV 1080P

13. 1920*1080 67.43 / 67.5 59.94 / 60 HDTV 1080P

No. Resolution H-freq(kHz) V-freq.(Hz) Proposed

1 640 x 350 @70Hz 31.468 70.09 EGA

2 720 x 400 @70Hz 31.469 70.08 DOS

3 640 x 480 @60Hz 31.469 59.94 VESA(VGA)

4 800 x 600 @60Hz 37.879 60.31 VESA(SVGA)

5 1024 x 768 @60Hz 48.363 60.00 VESA(XGA)

6 1152 x 864 @60Hz 54.348 60.053 VESA

7 1280 x 1024 @60Hz 63.981 60.020 VESA(SXGA)

8 1360 x 768 @60Hz 47.712 60.015 VESA(WXGA)

9 1920 x 1080 @60Hz 67.5 60.00 WUXGA(Reduced Blanking))

7.2. PC mode

LG 47LM760T User Manual
