LG 55EV5D - PRODUCT SPECIFICATIONS

ENGLISH
24
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18 hours (video)
Video signal Maximum resolution HDMI / DisplayPort: 3840 x 2160 @ 30 Hz
OPS: 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphics card
types.
Recommended
resolution
HDMI / DisplayPort / OPS: 1920 x 1080 @ 60 Hz
- This may not be supported on some OS or graphics card
types.
Horizontal frequency HDMI/ DisplayPort/ OPS: 30 kHz to 83 kHz
Vertical frequency HDMI/ DisplayPort/ OPS: 50 Hz to 60 Hz
Synchronization Separate/Digital
Input/ Output ports IR IN, RS-232C IN/OUT, AUDIO OUT, HDMI IN, DP IN/OUT, USB3.0 IN, LAN IN/OUT, HDMI
OUT, 16/22PIN POWER, LC IN/OUT
Embedded battery Applied
Environmental Conditions Operating Temperature 0 °C to 40 °C
Operating Humidity 10 % to 80 %
Storage Temperature -20 °C to 60 °C
Storage Humidity 5 % to 85 %
OLED Panel Pixel Pitch 0.630 mm (H) X 0.630 mm (V)
Power Rated Voltage AC 100-240 V ~ 50/60 Hz 3.0 A
Power Consumption On Mode: 190 W (Typ.)
Sleep Mode (HDMI, DisplayPort): ≤ 3.0 W
Off Mode: ≤ 0.5 W
Dimensions
(Width x Height x Depth)
/ Weight
Display Module (Back
metal plate assembled)
1382 x 1220.9 x 7.9 (mm) / 18.4 (kg) (55EV5D-2V)
1368.6 x 1220.9 x 7.9 (mm) / 18 (kg) (55EV5D-2EV)
2066.3 x 1220.9 x 7.9 (mm) / 27.4 (kg) (55EV5D-3V)
Signage Box 412.6 X 222.4 X 64.3 (mm) / 4.3 (kg)
T-con Box 312.2 X 213.4 X 16 (mm) / 1.6 (kg)
