LG 55G2 - USB Input

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.2. 3D mode
5.2.1. RF Input
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 1920*1080 45 60 74.25 HDTV 1080I Side by Side, Top & Bottom
2 1280*720 45 60 74.25 HDTV 720P Side by Side, Top & Bottom
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remark
1 1280*720p 45.00 60.00 74.25 Side by Side , Top & Bottom,
Single Frame Sequential
2 1920*1080i 33.75 60.00 74.25 Side by Side , Top & Bottom
3 1920*1080p 67.50 60.00 148.50 Side by Side , Top & Bottom
Checkerboard, Single Frame Sequential
Row Interleaving, Column Interleaving
4 1920*1080p 27.00 24.000 74.25 Side by Side , Top & Bottom
Checkerboard
5 1920*1080p 33.75 30.000 74.25 Side by Side, Top & Bottom
Checkerboard
5.2.5. HDMI 1.3(3D supported mode manually)
5.2.2. USB Input
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 1920*1080 33.75 30.00 74.25 HDTV 1080p Side by Side, Top & Bottom,
Checkerboard
5.2.3. HDMI-PC Input Input
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remark
1 1024*768 48.363 60.004 65.000 Side by Side , Top & Bottom
2 1280*768 47.776 59.870 79.500 Side by Side , Top & Bottom
3 1360*768 47.712 60.015 85.500 Side by Side , Top & Bottom
4 1280*720 45.00 60.00 74.25 Side by Side , Top & Bottom,
Single Frame Sequential
5 1920*1080 67.50 60.00 148.50 Side by Side , Top & Bottom
Checkerboard, Single Frame Sequential
Row Interleaving, Column Interleaving
5.2.4. RGB-PC Input
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Remark
1 1920*1080 67.5 60.000 148.5 Side by Side , Top & Bottom
2 1280*720 45.000 60.000 74.250 Side by Side , Top & Bottom
3 1360*768 47.712 60.015 85.50 Side by Side , Top & Bottom
4 1280*768 47.776 59.870 79.500 Side by Side , Top & Bottom
5 1024*768 48.363 60.00 65.00 Side by Side , Top & Bottom
