4. Trouble shooting - No video (AV)
Check input signal format.
Is it supported?
Check AV Cable for damage
for damage or open conductor
Check JK3800 CVBS Signal Line
AV1_CVBS_IN : L504
ok
ok
ok
No
Replace Jack
ok
Check CVBS_DET Signal
AV1_CVBS_DET : R3810
Replace R3810 or Jack
No
No
Check L9 Ace(IC101) Chip
Replace LG1152A(IC101)
or Main Board.
ok
No
Check L9 D-chip (IC100) Chip
Replace IC100 or Main Board.
