LG 55G2 - Interconnection - sub PCB( XXG2-UG Series )

Interconnection – sub PCB( XXG2-UG Series )
RF MOTION ASSY
To Main
SPK unit
4
WIFI ASSY
3
RF MOTION ASSY
2
1
Soft Touch + IR PCB
Soft Touch +
IR PCB
WIFI ASSY
32
