ENGLISH
65
CONTROLLING MULTIPLE PRODUCTS
• This only applies to certain models.
Use this method to connect several products to a single PC. You can control several products at a time by connecting
them to a single PC.
In the Option menu, the Set ID must be between 1 and 1000 without being duplicated.
Connecting cables
• Images may differ according to the model.
Connect the RS-232C cable as shown in the picture.
The RS-232C protocol is used for communication between the PC and product. You can turn the product on/off, select
an input source and adjust the OSD menu from your PC.
Monitor 4 Monitor 3 Monitor 2 Monitor 1 PC
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
RS-232C
IN
RS-232C
OUT
4P Cable (sold separately) RS-232C Gender RS-232C Cable
(sold separately)
PC Monitor 1 Monitor 2 Monitor 3 Monitor 4
RS-232C Cable (sold separately)

LG 55XE4F-B.AEU Specifications

General

Screen Size	55 inches
Panel Technology	IPS
Contrast Ratio	1200:1
Operating Temperature	0 °C to 40 °C
IP Rating	IP56
Orientation	Landscape/Portrait
Storage Temperature	-20 °C to 60 °C
Standby Power Consumption	0.5 W
Frequency	50/60Hz
Operating System	WebOS
Native Resolution	1920 x 1080 (FHD)
Viewing Angle (H x V)	178° x 178°
Response Time	8 ms
Input	HDMI, USB
Output	Audio Out
External Control	RS-232C, RJ45
Power Supply	AC 100-240V
Input Voltage	AC 100-240V
