LG 60LF67 Series - Page 87

Ê
çèéè êëìôîòð ê ëìôîõ
Main SOC
M1A-LGE2134
(IC101, DDR3 256MB)
30P HD LVDS wafer
51P FHD LVDS wafer
CK+/-, D0+/-, D1+/-, D2+/-_HDMI2
DDC_SCL/SDA_2, HDMI_CEC
Serial Flash
(8Mbit)
SPI_SCK/SDI/SDO/CS
System EEPROM
(256Kbit)
I2C_SCL/SDA
SPK_R
SPK_L
RXA0+/-~RXA4+/-, RXACK+/-
RXB0+/-~RXB4+/-, RXBCK+/-
AMP_SCL/SDA
NTP7515
Connector
AUD_MASTER_CLK,
AUD_LRCH,
AUD_LRCK, AUD_SCK
HDMI1
F-SCART
USB
DM/DP
USB1_OCP/CTL
SN1406035RGER
+5V_USB
PCM_A[0:7]
NAND FLASH
IC102 (1Gbit)
H27U1G8F2CTR-BC
T4LCX244FT Buffer
TS_DATA[0:7]
PCM_DATA[0:7]
PCM_A[8:14]
X-tal
24MHZ
SC1/AV2_CVBS_IN, SC1_R+/G+/B+
DTV/MNT_OUT, DTV/MNT_L/R_OUT
TU_SCL / SDA
Tuner
F/NIM
DEMOD_SCL/SDA
IF_N/P
IF_AGC
FE_TS_DATA[0:7]
LNB_TX
LNB_OUT, DEMOD_RESET
CI SLOT
OCP
REAR
SIDE
Jog KEY, LED_R, IR
ITALIANO
